Phoenix Contact CC Series Straight Wave Soldering Mount PCB Header, 4 Contact(s), 5 mm Pitch, 1 Row(s), Shrouded

View all PCB Headers

Subtotal (1 pack of 330 units)*

£581.03

(exc. VAT)

£697.24

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 02 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£581.03£1.761

*price indicative

RS Stock No.:
556-686
Mfr. Part No.:
1836939
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Header

Series

CC

Pitch

5mm

Current

12A

Number of Contacts

4

Housing Material

Liquid Crystal Polymer

Number of Rows

1

Orientation

Straight

Shrouded/Unshrouded

Shrouded

Connector System

COMBICON MSTB 2.5

Mount Type

Wave Soldering Mount

Contact Plating

Tin Plated

Contact Material

Copper Alloy

Row Pitch

5mm

Termination Type

Solder

Minimum Operating Temperature

-40°C

Contact Gender

Male

Maximum Operating Temperature

100°C

Tail Pin Length

2mm

Standards/Approvals

cULus Recognised, DIN EN 61340-5-1 (VDE 0300-5-1): 2008-07, IEC 60068-2-27:2008-02, IEC 60068-2-6:2007-12, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60512-9-1:2010-03, IEC 60664-1:2007-04, ISO 6988:1985-02, REACH, RoHS, UL 94 V0

Mating Pin Length

2mm

Voltage

32 V

COO (Country of Origin):
DE
The Phoenix Contact PCB header designed to integrate seamlessly into your electronic projects. Tailored for both flexibility and performance, this component stands out with its robust design and versatile mounting options. It accommodates varied connection technologies making it ideal for a wide range of applications. The intuitive Lock-and-Release mechanism ensures secure connections while allowing effortless disconnection when needed. Manufactured with high-quality materials, this PCB header yields impressive electrical properties, significantly enhancing the reliability and efficiency of your devices. From compact designs to complex systems, this component embodies the perfect blend of functionality and design, catering to modern engineering needs.

Automatic locking system facilitates quick and easy operation

Designed for optimal integration into surface-mount soldering processes

Offers exceptional stability with a screwable flange mechanism

Compatible with the COMBICON MSTB 2,5 plug-in system for enhanced connectivity

Constructed to meet strict European RoHS standards for environmental compliance

Equipped to withstand demanding thermal and electrical conditions

Supports a wide range of applications thanks to its compact size and versatility
