Molex 21657 Series Vertical Through Hole PCB Header, 4 Contact(s), 3 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 536-869
- Mfr. Part No.:
- 2165711034
- Brand:
- Molex
Bulk discount available
Subtotal (1 pack of 5 units)*
£11.79
(exc. VAT)
£14.15
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 240 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 - 4 | £11.79 | £2.358 |
| 5 - 9 | £10.85 | £2.17 |
| 10 + | £9.80 | £1.96 |
*price indicative
- RS Stock No.:
- 536-869
- Mfr. Part No.:
- 2165711034
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 21657 | |
| Product Type | PCB Header | |
| Pitch | 3mm | |
| Current | 13A | |
| Number of Contacts | 4 | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Connector System | Power, Wire-to-Board | |
| Contact Material | High Copper Alloy | |
| Contact Plating | Matt Tin | |
| Minimum Operating Temperature | -40°C | |
| Row Pitch | 3mm | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 125°C | |
| Tail Pin Length | 3.18mm | |
| Contact Gender | Female | |
| Standards/Approvals | No | |
| Voltage | 600 Vrms | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Series 21657 | ||
Product Type PCB Header | ||
Pitch 3mm | ||
Current 13A | ||
Number of Contacts 4 | ||
Housing Material Liquid Crystal Polymer | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Connector System Power, Wire-to-Board | ||
Contact Material High Copper Alloy | ||
Contact Plating Matt Tin | ||
Minimum Operating Temperature -40°C | ||
Row Pitch 3mm | ||
Termination Type Solder | ||
Maximum Operating Temperature 125°C | ||
Tail Pin Length 3.18mm | ||
Contact Gender Female | ||
Standards/Approvals No | ||
Voltage 600 Vrms | ||
- COO (Country of Origin):
- CN
The Molex Micro fit+ versa Color vertical header is specifically designed for efficient wire to board connections. With a robust 3.00mm pitch configuration, this product enables secure electrical contacts thanks to its four circuits and high copper alloy construction. The glow wire capability ensures safety during use, making it ideal for a variety of power applications. The combination of matte tin plating enhances durability while providing a sleek finish, and its vertical orientation allows for optimal space utilisation on PCBs. This powerful component not only meets industry compliance standards but also boasts a low halogen status, promoting eco friendly manufacturing practices. Experience reliability and innovation with this exceptional connector solution.
Durable construction ensures long lasting performance
Innovative design supports efficient assembly in space constrained applications
Low halogen status aligns with environmental standards
Glowing wire capability enhances safety in various applications
Compliant with multiple industry regulations for peace of mind
Vertical orientation streamlines PCB layout options
Easy locking mechanism improves connection stability
Matte tin plating provides excellent conductivity and corrosion resistance
