Phoenix Contact SMSTBA Series Angled Wave Soldering Mount PCB Header, 6 Contact(s), 5 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 521-580
- Mfr. Part No.:
- 1769845
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£140.49
(exc. VAT)
£168.59
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 19 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £140.49 | £2.81 |
*price indicative
- RS Stock No.:
- 521-580
- Mfr. Part No.:
- 1769845
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Header | |
| Series | SMSTBA | |
| Current | 12A | |
| Pitch | 5mm | |
| Housing Material | Polyamide | |
| Number of Contacts | 6 | |
| Number of Rows | 1 | |
| Orientation | Angled | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Wave Soldering Mount | |
| Connector System | COMBICON MSTB 2.5 | |
| Contact Plating | Tin Plated | |
| Contact Material | Copper Alloy | |
| Termination Type | Solder | |
| Row Pitch | 5mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 100°C | |
| Contact Gender | Male | |
| Tail Pin Length | 3.5mm | |
| Standards/Approvals | CSA, cULus Recognised, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-70:1995-12, IEC 60112, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, ISO 6988:1985-02, UL 94 V0, VDE | |
| Mating Pin Length | 3.5mm | |
| Voltage | 32 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Header | ||
Series SMSTBA | ||
Current 12A | ||
Pitch 5mm | ||
Housing Material Polyamide | ||
Number of Contacts 6 | ||
Number of Rows 1 | ||
Orientation Angled | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Wave Soldering Mount | ||
Connector System COMBICON MSTB 2.5 | ||
Contact Plating Tin Plated | ||
Contact Material Copper Alloy | ||
Termination Type Solder | ||
Row Pitch 5mm | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 100°C | ||
Contact Gender Male | ||
Tail Pin Length 3.5mm | ||
Standards/Approvals CSA, cULus Recognised, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-70:1995-12, IEC 60112, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, ISO 6988:1985-02, UL 94 V0, VDE | ||
Mating Pin Length 3.5mm | ||
Voltage 32 V | ||
- COO (Country of Origin):
- PL
The Phoenix Contact SMSTBA 2.5/6-G PCB header offers exceptional versatility for modern device design. Engineered for application adaptability, this connector caters to various connection technologies while maintaining a streamlined profile. With a nominal current capacity of 12 A and a rated voltage of 320 V, it is suitable for a broad range of electronic applications. Its robust construction and linear pinning ensure reliable connectivity, making it an ideal choice for PCB layouts that require precision and efficiency. The unit is designed for wave soldering, allowing for easy and effective assembly in both high-volume and bespoke production environments. The green housing and tin-plated contacts not only meet quality standards but also want to ensure compliance with WEEE and RoHS regulations, aligning with the industry's environmental goals.
Designed for high flexibility, accommodating various connection technologies
Angled connections enable multi-row arrangements on PCBs
WEEE and RoHS-compliant, ensuring adherence to environmental standards
Easy integration into existing systems with a standard pin connector pattern
Efficient wave soldering mounting type simplifies assembly processes
Reliable electrical properties with a low contact resistance for optimal performance
Durable construction suitable for various ambient conditions, supporting a temperature range from -40°C to 100°C
Supports a range of solder pins per potential, enhancing customisation capabilities in designs
