Phoenix Contact TVMSTB Series 90° Flange PCB Connector, 8 Contact(s), 5.08 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 520-073
- Mfr. Part No.:
- 1719118
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£515.08
(exc. VAT)
£618.10
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 27 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £515.08 | £10.302 |
*price indicative
- RS Stock No.:
- 520-073
- Mfr. Part No.:
- 1719118
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Connector | |
| Series | TVMSTB | |
| Current | 12A | |
| Pitch | 5.08mm | |
| Housing Material | Polyamide | |
| Number of Contacts | 8 | |
| Number of Rows | 1 | |
| Orientation | 90° | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Flange | |
| Connector System | COMBICON MSTB 2.5 | |
| Contact Material | Copper Alloy | |
| Contact Plating | Tin Plated | |
| Minimum Operating Temperature | -40°C | |
| Row Pitch | 5.08mm | |
| Termination Type | Screw | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 100°C | |
| Standards/Approvals | cULus Recognised, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-6:2007-12, IEC 60512-13-2:2006-02, IEC 60999-1:1999-11, ISO 6988:1985-02, UL 94 V0, VDE report | |
| Voltage | 40 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Connector | ||
Series TVMSTB | ||
Current 12A | ||
Pitch 5.08mm | ||
Housing Material Polyamide | ||
Number of Contacts 8 | ||
Number of Rows 1 | ||
Orientation 90° | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Flange | ||
Connector System COMBICON MSTB 2.5 | ||
Contact Material Copper Alloy | ||
Contact Plating Tin Plated | ||
Minimum Operating Temperature -40°C | ||
Row Pitch 5.08mm | ||
Termination Type Screw | ||
Contact Gender Female | ||
Maximum Operating Temperature 100°C | ||
Standards/Approvals cULus Recognised, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-6:2007-12, IEC 60512-13-2:2006-02, IEC 60999-1:1999-11, ISO 6988:1985-02, UL 94 V0, VDE report | ||
Voltage 40 V | ||
- COO (Country of Origin):
- SK
The Phoenix Contact PCB TWIN plug is engineered for exceptional connectivity and reliability in various applications. Designed within the TVMSTB 2.5/-STF product family, it stands out due to its robust construction and versatile features that cater to modern industrial needs. With its nominal current capacity of 12 A and a rated voltage of up to 400 V, it is suitable for demanding environments. The plug employs a screw connection with a tension sleeve, ensuring a secure fit that withstands mechanical stress. Its compact design allows for efficient use of space on PCBs, while the 5.08 mm pitch facilitates easy integration alongside other components. This device is the perfect choice for those seeking high-quality connector solutions for bus applications, providing ease of installation and maintenance for engineers and technicians alike.
Screw flange facilitates stable mounting on the PCB
Hot-dip tin-plated contacts ensure durability and conductivity
Wide range of compatible conductor cross-sections
Complies with international standards for safety and performance
Meets rigorous environmental testing standards for reliability
