Phoenix Contact MSTBA Series Right Angled Wave Soldering PCB Header, 7 Contact(s), 5.08mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 520-060
- Mfr. Part No.:
- 1714738
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£195.69
(exc. VAT)
£234.83
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 02 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
---|---|---|
1 + | £195.69 | £3.914 |
*price indicative
- RS Stock No.:
- 520-060
- Mfr. Part No.:
- 1714738
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Series | MSTBA | |
Pitch | 5.08mm | |
Number of Contacts | 7 | |
Number of Rows | 1 | |
Body Orientation | Right Angled | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Wave Soldering | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Series MSTBA | ||
Pitch 5.08mm | ||
Number of Contacts 7 | ||
Number of Rows 1 | ||
Body Orientation Right Angled | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Wave Soldering | ||
- COO (Country of Origin):
- CN
The Phoenix Contact PCB header is designed for efficient and reliable connectivity in various electronic applications. Featuring a simple yet effective mounting solution, this component is well-suited for automated assembly processes, ensuring dependable performance in challenging environments. Whether for commercial or industrial use, its robust construction and adherence to international standards guarantee safety and compliance. The product's sleek design allows for easy integration into existing setups, showcasing versatility for a range of tasks. The combination of remarkable electrical properties and thoughtful engineering sets this header apart, making it a preferred choice among professionals seeking quality and durability.
Optimised for wave soldering, ensuring easy assembly
Compatible with COMBICON MSTB 2,5 HC plug-in systems
Constructed with WEEE/RoHS-compliant materials, promoting environmental safety
Employs a linear pinning layout for straightforward PCB integration
Designed to operate in extreme temperatures ranging from -40 °C to 100 °C
Features a flammability rating of UL 94 V0 for enhanced safety
Offers a reliable nominal current of 16 A, allowing for robust performance
Weight-efficient design enhances transport and handling convenience
Specified with minimal mounting requirements to ease installation
Approved for various certifications, ensuring high-quality standards
Compatible with COMBICON MSTB 2,5 HC plug-in systems
Constructed with WEEE/RoHS-compliant materials, promoting environmental safety
Employs a linear pinning layout for straightforward PCB integration
Designed to operate in extreme temperatures ranging from -40 °C to 100 °C
Features a flammability rating of UL 94 V0 for enhanced safety
Offers a reliable nominal current of 16 A, allowing for robust performance
Weight-efficient design enhances transport and handling convenience
Specified with minimal mounting requirements to ease installation
Approved for various certifications, ensuring high-quality standards
