Molex 70247 Series Right Angle Through Hole PCB Header, 14 Contact(s), 2.54 mm Pitch, 2 Row, Shrouded
- RS Stock No.:
- 507-528
- Mfr. Part No.:
- 70247-1451
- Brand:
- Molex
Subtotal (1 tray of 200 units)*
£198.22
(exc. VAT)
£237.86
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 26 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tray(s) | Per Tray | Per unit* |
|---|---|---|
| 1 + | £198.22 | £0.991 |
*price indicative
- RS Stock No.:
- 507-528
- Mfr. Part No.:
- 70247-1451
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Product Type | PCB Header | |
| Series | 70247 | |
| Current | 2.5A | |
| Pitch | 2.54mm | |
| Number of Contacts | 14 | |
| Housing Material | Polyester | |
| Number of Rows | 2 | |
| Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Contact Plating | Gold | |
| Minimum Operating Temperature | -55°C | |
| Termination Type | Solder | |
| Row Pitch | 2.54mm | |
| Maximum Operating Temperature | 120°C | |
| Tail Pin Length | 3.05mm | |
| Standards/Approvals | 94V-0, CSA LR19980, UL E29179 | |
| Voltage | 250 V | |
| Distrelec Product Id | 304-57-539 | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Product Type PCB Header | ||
Series 70247 | ||
Current 2.5A | ||
Pitch 2.54mm | ||
Number of Contacts 14 | ||
Housing Material Polyester | ||
Number of Rows 2 | ||
Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Contact Plating Gold | ||
Minimum Operating Temperature -55°C | ||
Termination Type Solder | ||
Row Pitch 2.54mm | ||
Maximum Operating Temperature 120°C | ||
Tail Pin Length 3.05mm | ||
Standards/Approvals 94V-0, CSA LR19980, UL E29179 | ||
Voltage 250 V | ||
Distrelec Product Id 304-57-539 | ||
- COO (Country of Origin):
- MY
The TE Connectivity 2.54mm Pitch C-Grid Header is designed with precision engineering for reliable connections in electronic applications. This low-profile, dual-row component allows for effective wire-to-board signal transmission, featuring 14 circuits equipped with selective gold plating for enhanced conductivity. Its right-angle configuration optimizes space while ensuring ease of insertion on printed circuit boards. Constructed from durable materials, the header accommodates a wide temperature range, catering to diverse operational conditions. The unique design also incorporates shrouding to prevent misalignment, making it ideal for high-density environments. With proven compliance to industry standards, this product ensures dependable performance and longevity in critical applications.
