WAGO 734 Series Angled Through Hole Header, 2 Contact(s), 3.5 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 222-745
- Distrelec Article No.:
- 304-29-996
- Mfr. Part No.:
- 734-262
- Brand:
- WAGO
Subtotal (1 box of 200 units)*
£94.94
(exc. VAT)
£113.93
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £94.94 | £0.475 |
*price indicative
- RS Stock No.:
- 222-745
- Distrelec Article No.:
- 304-29-996
- Mfr. Part No.:
- 734-262
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Series | 734 | |
| Product Type | Header | |
| Pitch | 3.5mm | |
| Current | 10A | |
| Housing Material | Polyamide 66 | |
| Number of Contacts | 2 | |
| Number of Rows | 1 | |
| Orientation | Angled | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | MCS | |
| Mount Type | Through Hole | |
| Contact Plating | Tin | |
| Contact Material | Electrolytic Copper | |
| Termination Type | Through-Hole Reflow (THR) Soldering | |
| Minimum Operating Temperature | 60°C | |
| Row Pitch | 3.5mm | |
| Tail Pin Length | 3.8mm | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 100°C | |
| Standards/Approvals | RoHS | |
| Voltage | 160 V | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Series 734 | ||
Product Type Header | ||
Pitch 3.5mm | ||
Current 10A | ||
Housing Material Polyamide 66 | ||
Number of Contacts 2 | ||
Number of Rows 1 | ||
Orientation Angled | ||
Shrouded/Unshrouded Shrouded | ||
Connector System MCS | ||
Mount Type Through Hole | ||
Contact Plating Tin | ||
Contact Material Electrolytic Copper | ||
Termination Type Through-Hole Reflow (THR) Soldering | ||
Minimum Operating Temperature 60°C | ||
Row Pitch 3.5mm | ||
Tail Pin Length 3.8mm | ||
Contact Gender Male | ||
Maximum Operating Temperature 100°C | ||
Standards/Approvals RoHS | ||
Voltage 160 V | ||
- COO (Country of Origin):
- DE
The Wago THT Male Header from wago is a versatile and efficient connector designed for robust applications in various environments. Engineered for dependable PCB mounting, this component offers both straight and angled configurations to cater to diverse installation needs. Its innovative design features 100% protection against mismating, ensuring that only compatible connectors engage. With a pin spacing of 3.81 mm, the header accommodates standard solder pin dimensions for seamless integration into existing systems.
Compatible with coding options to prevent improper connections
Designed with anti rotation protection for secure installations
Lightweight at just 06 g facilitating ease of handling and assembly
Offers a wide temperature range for reliable operation in extreme conditions
Gold plated contact surfaces for enhanced conductivity
Compliant with international RoHS standards for environmental safety
