Renesas, PS9317L2-V-AX Photodiode Output Optocoupler, Surface Mount, 6-Pin DIP

View all Optocouplers
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
186-4385
Mfr. Part No.:
PS9317L2-V-AX
Brand:
Renesas Electronics
Find similar products by selecting one or more attributes.
Select all

Brand

Renesas Electronics

Mounting Type

Surface Mount

Output Device

Photodiode

Maximum Forward Voltage

1.9V

Number of Channels

1

Number of Pins

6

Package Type

DIP

Typical Rise Time

35ns

Maximum Input Current

10 mA

Isolation Voltage

5 kVrms

Typical Fall Time

40ns

COO (Country of Origin):
JP
The PS9317L and PS9317L2 are optical coupled high-speed, active low type isolators containing a GaAlAs LED on the input side and a photodiode and a signal processing circuit on the output side on one chip. The PS9317L and PS9317L2 are designed specifically for high common mode transient immunity (CMR) and low pulse width distortion. The PS9317L is lead bending type (Gull-wing) for surface mounting. The PS9317L2 is lead bending type for long creepage distance (Gull-wing) for surface mount.

Pulse width distortion (tPHL  tPLH = 35 ns MAX.)
High common mode transient immunity (CMH, CML = 15 kV/s MIN.)
Half size of 8-pin DIP
Long creepage distance (8 mm MIN. : PS9317L2)
High-speed (10 Mbps)
High isolation voltage (BV = 5 000 Vr.m.s.)
Open collector output
Pb-Free product
APPLICATIONS
Measurement equipment
PDP
FA Network
