- RS Stock No.:
- 233-3107
- Mfr. Part No.:
- TSZ182IDT
- Brand:
- STMicroelectronics
Available to back order for despatch 30/06/2025
Price Each (On a Reel of 2500)
£0.912
(exc. VAT)
£1.094
(inc. VAT)
Units | Per unit | Per Reel* |
---|---|---|
2500 + | £0.912 | £2,280.00 |
*price indicative
- RS Stock No.:
- 233-3107
- Mfr. Part No.:
- TSZ182IDT
- Brand:
- STMicroelectronics
Technical Reference
Legislation and Compliance
Product Details
The STMicroelectronics TSZ182 are single and dual operational amplifiers featuring very low offset voltages with virtually zero drift versus temperature changes. The TSZ181, TSZ182 offer rail-to-rail input and output, excellent speed/power consumption ratio, and 3 MHz gain bandwidth product, while consuming just 1 mA at 5 V. The device also features an ultra-low input bias current. These features make the TSZ18x ideal for high-accuracy high-bandwidth sensor interfaces.
Very high accuracy and stability: offset voltage 25 μV max. at 25 °C, 35 μV over full temperature range (-40 °C to 125 °C)
Rail-to-rail input and output
Low supply voltage: 2.2 - 5.5 V
Low power consumption: 1 mA max. at 5 V
Gain bandwidth product: 3 MHz
Automotive qualification
Extended temperature range: -40 to 125 °C
Micro packages: DFN8 2x2, SO8 and MiniSO8
Rail-to-rail input and output
Low supply voltage: 2.2 - 5.5 V
Low power consumption: 1 mA max. at 5 V
Gain bandwidth product: 3 MHz
Automotive qualification
Extended temperature range: -40 to 125 °C
Micro packages: DFN8 2x2, SO8 and MiniSO8
Specifications
Attribute | Value |
---|---|
Amplifier Type | Zero Drift |
Mounting Type | Surface Mount |
Package Type | SO8 |
Power Supply Type | Single |
Number of Channels per Chip | 2 |
Pin Count | 8 |
Typical Single Supply Voltage | 5.5 V |
Typical Gain Bandwidth Product | 3MHz |
Rail to Rail | Rail to Rail Input/Output |
