Texas Instruments, Operational Amplifier, 10 MHz, 14-Pin 18V TSSOP
- RS Stock No.:
- 168-5025
- Mfr. Part No.:
- OPA4172IPW
- Brand:
- Texas Instruments
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 168-5025
- Mfr. Part No.:
- OPA4172IPW
- Brand:
- Texas Instruments
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Texas Instruments | |
| Product Type | Operational Amplifier | |
| Mount Type | Surface | |
| Package Type | TSSOP | |
| Number of Channels | 4 | |
| Pin Count | 14 | |
| GBP - Gain Bandwidth Product | 10MHz | |
| Minimum Supply Voltage | 2.25V | |
| Maximum Supply Voltage | 18V | |
| Minimum Operating Temperature | -40°C | |
| Vos - Input Offset Voltage | ±1.15 mV | |
| Slew Rate | 10V/μs | |
| Input Bias Current | ±14 nA | |
| Maximum Operating Temperature | 125°C | |
| Height | 1.05mm | |
| Series | OPA4172 | |
| Standards/Approvals | RoHS | |
| Length | 5.1mm | |
| Output Current | 75mA | |
| Automotive Standard | AEC-Q100 | |
| Input Offset Current | 3 nA | |
| Select all | ||
|---|---|---|
Brand Texas Instruments | ||
Product Type Operational Amplifier | ||
Mount Type Surface | ||
Package Type TSSOP | ||
Number of Channels 4 | ||
Pin Count 14 | ||
GBP - Gain Bandwidth Product 10MHz | ||
Minimum Supply Voltage 2.25V | ||
Maximum Supply Voltage 18V | ||
Minimum Operating Temperature -40°C | ||
Vos - Input Offset Voltage ±1.15 mV | ||
Slew Rate 10V/μs | ||
Input Bias Current ±14 nA | ||
Maximum Operating Temperature 125°C | ||
Height 1.05mm | ||
Series OPA4172 | ||
Standards/Approvals RoHS | ||
Length 5.1mm | ||
Output Current 75mA | ||
Automotive Standard AEC-Q100 | ||
Input Offset Current 3 nA | ||
- COO (Country of Origin):
- MY
Precision Operational Amplifiers, OPA Series
Precision operational amplifiers from Texas Instruments Burr Brown OPA series are suitable for demanding applications requiring high accuracy and low parametric drift with time and temperature. Typical applications include transducer and strain gauge amplifiers, precision integrators, Active filters and high accuracy instrumentation. Many of these devices are available in single, dual and quad configurations, in both through-hole and SMT formats.
