Bourns Non-Resettable Fuse 500mA, 125V ac
- RS Stock No.:
- 191-4191
- Mfr. Part No.:
- SF-2410HI050T-2
- Brand:
- Bourns
Subtotal (1 reel of 1000 units)*
£407.00
(exc. VAT)
£488.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 16 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £0.407 | £407.00 |
*price indicative
- RS Stock No.:
- 191-4191
- Mfr. Part No.:
- SF-2410HI050T-2
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Current Rating | 500mA | |
| Product Type | Non-Resettable Fuse | |
| Voltage | 125V ac | |
| Fuse Speed | HI | |
| Body Material | Ceramic | |
| Width | 2.6mm | |
| Height | 2.6mm | |
| Minimum Operating Temperature | 125°C | |
| Fuse Characteristics | High Inrush | |
| Maximum Operating Temperature | -55°C | |
| Breaking Capacity | 300A | |
| Package Type | Reel | |
| Standards/Approvals | RoHS, UL 248-14 | |
| Depth | 6.1mm | |
| Series | SF-2410HI-T | |
| Package Size | 2410 | |
| Resistance | 346.2mΩ | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Current Rating 500mA | ||
Product Type Non-Resettable Fuse | ||
Voltage 125V ac | ||
Fuse Speed HI | ||
Body Material Ceramic | ||
Width 2.6mm | ||
Height 2.6mm | ||
Minimum Operating Temperature 125°C | ||
Fuse Characteristics High Inrush | ||
Maximum Operating Temperature -55°C | ||
Breaking Capacity 300A | ||
Package Type Reel | ||
Standards/Approvals RoHS, UL 248-14 | ||
Depth 6.1mm | ||
Series SF-2410HI-T | ||
Package Size 2410 | ||
Resistance 346.2mΩ | ||
- COO (Country of Origin):
- TW
Single blow fuse for overcurrent protection
Ceramic tube design for high inrush fusing speed applications
Surface mount packaging for automated assembly
Halogen free
Applications
Notebooks
LCD Monitors
LCD Backlight Inverters
POE, POE+
PC Servers
Power Supplies
Battery Protection
White Goods
