Bourns Non-Resettable Fuse 1.5A, 125V ac
- RS Stock No.:
- 191-4563
- Mfr. Part No.:
- SF-2410HI150T-2
- Brand:
- Bourns
Subtotal (1 tape of 10 units)*
£6.98
(exc. VAT)
£8.38
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 590 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 10 + | £0.698 | £6.98 |
*price indicative
- RS Stock No.:
- 191-4563
- Mfr. Part No.:
- SF-2410HI150T-2
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Non-Resettable Fuse | |
| Current Rating | 1.5A | |
| Voltage | 125V ac | |
| Fuse Speed | HI | |
| Body Material | Ceramic | |
| Width | 2.6mm | |
| Height | 2.6mm | |
| Fuse Characteristics | High Inrush | |
| Minimum Operating Temperature | 125°C | |
| Maximum Operating Temperature | -55°C | |
| Breaking Capacity | 300A | |
| Package Type | Reel | |
| Standards/Approvals | UL 248-14, RoHS | |
| Depth | 6.1mm | |
| Series | SF-2410HI-T | |
| Package Size | 2410 | |
| Resistance | 57mΩ | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Non-Resettable Fuse | ||
Current Rating 1.5A | ||
Voltage 125V ac | ||
Fuse Speed HI | ||
Body Material Ceramic | ||
Width 2.6mm | ||
Height 2.6mm | ||
Fuse Characteristics High Inrush | ||
Minimum Operating Temperature 125°C | ||
Maximum Operating Temperature -55°C | ||
Breaking Capacity 300A | ||
Package Type Reel | ||
Standards/Approvals UL 248-14, RoHS | ||
Depth 6.1mm | ||
Series SF-2410HI-T | ||
Package Size 2410 | ||
Resistance 57mΩ | ||
- COO (Country of Origin):
- TW
Single blow fuse for overcurrent protection
Ceramic tube design for high inrush fusing speed applications
Surface mount packaging for automated assembly
Halogen free
Applications
Notebooks
LCD Monitors
LCD Backlight Inverters
POE, POE+
PC Servers
Power Supplies
Battery Protection
White Goods
