- RS Stock No.:
- 196-9025
- Mfr. Part No.:
- DG409DYZ
- Brand:
- Renesas Electronics
1862 In stock - FREE next working day delivery available
Price Each (In a Tube of 48)
£3.028
(exc. VAT)
£3.634
(inc. VAT)
Units | Per unit | Per Tube* |
---|---|---|
48 - 96 | £3.028 | £145.344 |
144 - 480 | £2.659 | £127.632 |
528 - 960 | £2.589 | £124.272 |
1008 - 2496 | £2.523 | £121.104 |
2544 + | £2.459 | £118.032 |
*price indicative
- RS Stock No.:
- 196-9025
- Mfr. Part No.:
- DG409DYZ
- Brand:
- Renesas Electronics
Technical Reference
Legislation and Compliance
Product Details
The Renesas Electronics DG409 Differential 4-Channel monolithic CMOS analog multiplexers is a drop-in replacements for the popular DG508A and DG509A series devices. They each include an array of eight analog switches, a TTL/CMOS compatible digital decode circuit for channel selection, a voltage reference for logic thresholds and an ENABLE input for device selection when several multiplexers are present.
ON Resistance (Max, 25°C) 100O
Low Power Consumption (PD) <11mW
Low Charge Injection
Upgrade from DG508A/DG509A
TTL, CMOS Compatible
Single or Split Supply Operation
Pb-Free Plus Anneal Available (RoHS Compliant)
Low Power Consumption (PD) <11mW
Low Charge Injection
Upgrade from DG508A/DG509A
TTL, CMOS Compatible
Single or Split Supply Operation
Pb-Free Plus Anneal Available (RoHS Compliant)
Specifications
Attribute | Value |
---|---|
Logic Family | CMOS, TTL |
Logic Function | Multiplexer |
Demultiplexing Capability | 1-of-4 |
Pin Count | 16 |
Number of Elements per Chip | 2, 2 |
Mounting Type | Surface Mount |
Package Type | SOIC |
