Maxim Integrated DG406EWI+ Multiplexer Dual 16:1 5 to 30 V, 28-Pin SOIC
- RS Stock No.:
- 190-5701P
- Mfr. Part No.:
- DG406EWI+
- Brand:
- Maxim Integrated
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 190-5701P
- Mfr. Part No.:
- DG406EWI+
- Brand:
- Maxim Integrated
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Maxim Integrated | |
| Pin Count | 28 | |
| Mounting Type | Surface Mount | |
| Package Type | SO | |
| Dimensions | 18.1 x 7.6 x 2.35mm | |
| Maximum Operating Temperature | +85 °C | |
| Minimum Operating Temperature | -40 °C | |
Select all | ||
|---|---|---|
Brand Maxim Integrated | ||
Pin Count 28 | ||
Mounting Type Surface Mount | ||
Package Type SO | ||
Dimensions 18.1 x 7.6 x 2.35mm | ||
Maximum Operating Temperature +85 °C | ||
Minimum Operating Temperature -40 °C | ||
Pin-Compatible Plug-In Upgrade for Industry Standard DG406/DG407
Guaranteed Matching Between Channels, 8Ω (Max)
Guaranteed On-Resistance Flatness, 9Ω (Max)
Guaranteed Low Charge Injection, 15pC (Max)
Low On-Resistance 100Ω (Max)
Input Leakage, 5nA Max at +85°C
Low Power Consumption, 1.25mW (Max)
Rail-to-Rail Signal Handling
Digital Input Controls TTL/CMOS Compatible
ESD Protection > 2000V
Applications
Audio Signal Routing
Communication Systems
Data Acquisition Systems
Guidance and Control Systems
Sample-and-Hold Circuits
Test Equipment
Guaranteed Matching Between Channels, 8Ω (Max)
Guaranteed On-Resistance Flatness, 9Ω (Max)
Guaranteed Low Charge Injection, 15pC (Max)
Low On-Resistance 100Ω (Max)
Input Leakage, 5nA Max at +85°C
Low Power Consumption, 1.25mW (Max)
Rail-to-Rail Signal Handling
Digital Input Controls TTL/CMOS Compatible
ESD Protection > 2000V
Applications
Audio Signal Routing
Communication Systems
Data Acquisition Systems
Guidance and Control Systems
Sample-and-Hold Circuits
Test Equipment
