Maxim Integrated MAX396EWI+ Multiplexer Single 16:1 2.7 to 16 V, 28-Pin SOIC

View this category

Subtotal (1 tube of 25 units)*

£432.25

(exc. VAT)

£518.75

(inc. VAT)

Add to Basket
Select or type quantity
Being discontinued
  • Final 50 unit(s), ready to ship
Units
Per unit
Per Tube*
25 +£17.29£432.25

*price indicative

RS Stock No.:
190-4686
Mfr. Part No.:
MAX396EWI+
Brand:
Maxim Integrated
Find similar products by selecting one or more attributes.
Select all

Brand

Maxim Integrated

Pin Count

28

Mounting Type

Surface Mount

Package Type

SO

Dimensions

18.1 x 7.6 x 2.35mm

Minimum Operating Temperature

-40 °C

Maximum Operating Temperature

+85 °C

Pin Compatible with MAX306/MAX307, DG406/DG407, DG506A/DG507A
Single-Supply Operation (+2.7V to +16V)
Dual-Supply Operation (±2.7V to ±8V)
Low On-Resistance (100Ω max)
Guaranteed RON Match Between Channels (6Ω max)
Guaranteed RON Flatness over Specified Signal Range (10Ω max)
Guaranteed Low Charge Injection (5pC max)
Input Off-Leakage Current < 1nA at +85°C
Output Off-Leakage Current < 2.5nA at +85°C
Low Power Consumption < 10μW
TTL/CMOS Compatible
Applications
Audio-Signal Routing
Automated Test Equipment (ATE)
Avionics
Battery-Powered Applications
Communication Systems
Industrial Process Controls
Low-Voltage Data Acquisition Systems
Sample-and-Hold Circuits
