Fluke 77-III Handheld Digital Multimeter, 10A ac Max, 10A dc Max, 1000V ac Max
- RS Stock No.:
- 284-2109
- Mfr. Part No.:
- 1639145
- Brand:
- Fluke
- RS Stock No.:
- 284-2109
- Mfr. Part No.:
- 1639145
- Brand:
- Fluke
Select all | Attribute | Value |
|---|---|---|
| Brand | Fluke | |
| Multimeter Type | Handheld | |
| Model Number p | 77-III | |
| Functions Measured | AC Current, AC Voltage, DC Current, DC Voltage, Diode, Resistance | |
| Absolute Maximum DC Current Measurement | 10A dc | |
| Absolute Maximum Resistance Measurement | 32MΩ | |
| Absolute Maximum DC Voltage Measurement | 1000V dc | |
| Absolute Maximum AC Voltage Measurement | 1000V ac | |
| Absolute Maximum AC Current Measurement | 10A ac | |
| Maximum Frequency | 1kHz | |
| AC Current Measurement Resolution | 0.01mA ac | |
| DC Current Measurement Resolution | 0.01mA dc | |
| DC Voltage Measurement Resolution | 0.1mV dc | |
| Resistance Measurement Resolution | 100mΩ | |
| AC Voltage Measurement Resolution | 1mV ac | |
| Safety Category Level | CAT II, CAT III | |
| Best DC Current Accuracy | ±1.5% + 2 Digits | |
| Safety Category Voltage | 600 V, 1000 V | |
| Battery Type | 9V | |
| Best DC Voltage Accuracy | ±0.4% + 1 Digit | |
| Maximum Operating Temperature | +50°C | |
| Best Resistance Measurement Accuracy | ±2% + 1 Digit | |
| Length | 190mm | |
| Dimensions | 190 x 89 x 37mm | |
| Best AC Voltage Accuracy | ±2% + 2 Digits | |
| Minimum Operating Temperature | 0°C | |
| Height | 37mm | |
| Best AC Current Accuracy | ±2.5% + 2 Digits | |
| Width | 89mm | |
| Weight | 356g | |
| Select all | ||
|---|---|---|
Brand Fluke | ||
Multimeter Type Handheld | ||
Model Number p 77-III | ||
Functions Measured AC Current, AC Voltage, DC Current, DC Voltage, Diode, Resistance | ||
Absolute Maximum DC Current Measurement 10A dc | ||
Absolute Maximum Resistance Measurement 32MΩ | ||
Absolute Maximum DC Voltage Measurement 1000V dc | ||
Absolute Maximum AC Voltage Measurement 1000V ac | ||
Absolute Maximum AC Current Measurement 10A ac | ||
Maximum Frequency 1kHz | ||
AC Current Measurement Resolution 0.01mA ac | ||
DC Current Measurement Resolution 0.01mA dc | ||
DC Voltage Measurement Resolution 0.1mV dc | ||
Resistance Measurement Resolution 100mΩ | ||
AC Voltage Measurement Resolution 1mV ac | ||
Safety Category Level CAT II, CAT III | ||
Best DC Current Accuracy ±1.5% + 2 Digits | ||
Safety Category Voltage 600 V, 1000 V | ||
Battery Type 9V | ||
Best DC Voltage Accuracy ±0.4% + 1 Digit | ||
Maximum Operating Temperature +50°C | ||
Best Resistance Measurement Accuracy ±2% + 1 Digit | ||
Length 190mm | ||
Dimensions 190 x 89 x 37mm | ||
Best AC Voltage Accuracy ±2% + 2 Digits | ||
Minimum Operating Temperature 0°C | ||
Height 37mm | ||
Best AC Current Accuracy ±2.5% + 2 Digits | ||
Width 89mm | ||
Weight 356g | ||
RoHS Status: Not Applicable
Fluke 73 Series III Multimeters
Digital display with analogue bargraph
3200 count autoranging and manual range selection
Touch Hold® to automatically capture stable readings
Automatic power down if left unused when switched on to preserve battery life
Protective holster
Voltage, ohms, continuity and diode measurement
Voltage measurements up to 600V ac/dc with 0.1mV maximum resolution
Complies with EN61010-1 (safety standard) 600V cat II, over-voltage protection to 4KV
