Jumo 701540 LCD Digital Panel Multi-Function Meter for Temperature, 36mm x 76mm

View this category
Unavailable
RS will no longer stock this product.
RS Stock No.:
278-917
Mfr. Part No.:
701540/821-02-061
Brand:
Jumo
Find similar products by selecting one or more attributes.
Select all

Brand

Jumo

Properties Measured

Temperature

Display Type

LCD

Cutout Height

36mm

Cutout Width

76mm

Depth

56mm

Number of Digits

3

Series

701540

COO (Country of Origin):
DE
The Jumo Digital Indicator for panel mounting in format 76 x 36 mm can be used for Fe-CuNiJ, Fe-CuNiL, NiCr-NiK. It is for a simple presentation of temperature or other process variables. The actual value is shown on a three digit, backlight 13mm high display. Limit value exceedance are monitored on a 10A relay (changeover contact) and shown with a LED. 3 bottoms on the front site allow the configuration of the alarm suppression and the switching hysteresis. The voltage supply range is between AC 230 V + 10% / -15%, 48 to 63 Hz.

Electrical connection is on the backside via screw terminal
Display has cULus and GOST approval
