Eaton MSC-D Motor Starter, DOL, 415V ac, 4 kW, 3 Phase, IP20
- RS Stock No.:
- 251-657
- Mfr. Part No.:
- 199605 MSC-D-10-M11(230V50HZ)-PI
- Brand:
- Eaton
Subtotal (1 unit)*
£228.94
(exc. VAT)
£274.73
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 29 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £228.94 |
*price indicative
- RS Stock No.:
- 251-657
- Mfr. Part No.:
- 199605 MSC-D-10-M11(230V50HZ)-PI
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Power Rating | 4kW | |
| Product Type | Motor Starter | |
| Sub Type | DOL | |
| Number of Phases | 3 | |
| Current Rating | 8.5A | |
| Mount Type | DIN Rail | |
| IP Rating | IP20 | |
| Overall Length | 115mm | |
| Maximum Voltage | 415V ac | |
| Overall Width | 45mm | |
| Standards/Approvals | IEC/EN 60947-4-1 VDE 0660 | |
| Hazardous Area Certification | NO | |
| Overall Depth | 214mm | |
| Series | MSC-D | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Power Rating 4kW | ||
Product Type Motor Starter | ||
Sub Type DOL | ||
Number of Phases 3 | ||
Current Rating 8.5A | ||
Mount Type DIN Rail | ||
IP Rating IP20 | ||
Overall Length 115mm | ||
Maximum Voltage 415V ac | ||
Overall Width 45mm | ||
Standards/Approvals IEC/EN 60947-4-1 VDE 0660 | ||
Hazardous Area Certification NO | ||
Overall Depth 214mm | ||
Series MSC-D | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
The Eaton DOL starter from the series MSC-D is engineered for reliability and high performance in motor control applications. With its robust construction, it is suitable for use with three-phase motors up to 4 kW, allowing for smooth operation under varying load conditions. The starter effectively manages current overloads with an adjustable setting range, ensuring maximum safety and longevity of the motors. Designed to operate in a diverse range of environmental conditions, it features a degree of protection rated to IP20, making it a versatile solution for industrial settings. Incorporating a short-circuit release, the starter enhances operational safety, while its compact design promotes easy mounting on DIN rails for streamlined installation. This product is compatible with efficiency-class IE3 motors, further reinforcing its commitment to modern energy standards.
Designed for direct online starting of three-phase motors
Fitted with temperature compensated overload protection for enhanced safety
Provides short-circuit protection to safeguard against electrical faults
Capable of operating within a wide temperature range, supporting demanding environments
Constructed with push-in terminals for quick and efficient electrical connections
Complies with international electrical standards for reliability in global markets
Features dual-frequency coil technology for stable performance across frequencies
Lightweight yet durable design aids in easy installation and long-term use
