Infineon, Brushless DC Motor Motor Driver IC 41-Pin, PQFN
- RS Stock No.:
- 258-3761
- Mfr. Part No.:
- IMM101T046MXUMA1
- Brand:
- Infineon
Subtotal (1 reel of 2000 units)*
£8,360.00
(exc. VAT)
£10,040.00
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 2,000 unit(s) shipping from 27 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 2000 + | £4.18 | £8,360.00 |
*price indicative
- RS Stock No.:
- 258-3761
- Mfr. Part No.:
- IMM101T046MXUMA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Product Type | Motor Driver IC | |
| Motor Type | Brushless DC Motor | |
| Configuration | Ground | |
| Mount Type | Surface | |
| Package Type | PQFN | |
| Pin Count | 41 | |
| Output Current | 4A | |
| Minimum Supply Voltage | -0.3V | |
| Maximum Supply Voltage | 600V | |
| Minimum Operating Temperature | -40°C | |
| Typical Switching Frequency | 120kHz | |
| Maximum Operating Temperature | 115°C | |
| Standards/Approvals | IEC 60335 ('Class B') | |
| Height | 0.9mm | |
| Length | 12mm | |
| Series | IMM100 | |
| Inverter Power Rating | 28.4W | |
| Supply Current | 20mA | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Product Type Motor Driver IC | ||
Motor Type Brushless DC Motor | ||
Configuration Ground | ||
Mount Type Surface | ||
Package Type PQFN | ||
Pin Count 41 | ||
Output Current 4A | ||
Minimum Supply Voltage -0.3V | ||
Maximum Supply Voltage 600V | ||
Minimum Operating Temperature -40°C | ||
Typical Switching Frequency 120kHz | ||
Maximum Operating Temperature 115°C | ||
Standards/Approvals IEC 60335 ('Class B') | ||
Height 0.9mm | ||
Length 12mm | ||
Series IMM100 | ||
Inverter Power Rating 28.4W | ||
Supply Current 20mA | ||
Automotive Standard No | ||
The Infineon iMOTION IPM integrating MCE 2.0 motor controller and three phase inverter with 600 V / 1.26 Ω RDS(on) MOSFETs in 12x12 mm PQFN package.
Storage of motor parameters
Multiple protections features
