Finder Level Monitoring Relay, 1 Phase, SPDT, DIN Rail

View all Monitoring Relays
Bulk discount available

Subtotal (1 unit)*

£80.65

(exc. VAT)

£96.78

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 10 unit(s) ready to ship
  • Plus 11 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£80.65
5 +£77.34

*price indicative

RS Stock No.:
776-1579
Mfr. Part No.:
72.01.8.024.0002
Brand:
Finder
Find similar products by selecting one or more attributes.
Select all

Brand

Finder

Monitoring Application

Level

Electrical Phase

1

Contact Configuration

SPDT

Mounting Type

DIN Rail

Time Delay

0.5 → 7s

Series

72

Terminal Type

Screw

Width

35mm

Length

58mm

Dimensions

58 x 35 x 84mm

Operating Temperature Range

+60°C

Minimum Operating Temperature

-20°C

Maximum Operating Temperature

+60°C

Height

84mm

COO (Country of Origin):
IT

Finder Series 72 Monitoring Relay, 1 Electrical Phase, 16A Current - 72.01.8.024.0002


This monitoring relay is designed for level monitoring applications, providing essential control for various systems. With dimensions of 58 x 35 x 84mm, it fits seamlessly onto a DIN rail for easy installation. The product operates within a temperature range of -20 °C to +60 °C, making it suitable for a range of environments.

Features & Benefits


• SPDT contact configuration offers versatile switching options
• Time delay adjustable from 0.5 to 7 seconds enhances flexibility
• Current range of 16/30A supports various load requirements
• Screw terminals enable secure and easy connections
• CE certified ensures compliance with European standards
• Reinforced insulation provides added safety during operation

Applications


• Ideal for level control in swimming pools
• Used in bottling and milk processing plants
• Essential for managing control panels for pumps
• Suitable for industrial washing machines
• Facilitates level monitoring in various conductive liquids

What types of liquids can be monitored using this relay?


It is suitable for conductive liquids such as mains water, sewage, wine, and milk. However, it should not be used with demineralised water, oil, or liquids with a high alcohol content.

How can the sensitivity be adjusted for different applications?


The sensitivity can be adjusted to a range of 5–150 kΩ, allowing for tailored responses based on the fluid's conductivity.

What safety features are integrated into the design?


The relay includes reinforced insulation of 6 kV between supply and contacts, ensuring protection against potential electrical faults during operation.

How does the time delay function improve performance?


The adjustable time delay allows for better control in filling or emptying operations, preventing rapid switching that can damage equipment.

What is the voltage supply range for this relay?


It is compatible with multiple voltage supplies, including 24V AC/DC, 110–125V AC, and 230–240V AC, accommodating various settings and requirements.
