TDK 750nF MLCC, 900V dc V, ±20% , SMD
- RS Stock No.:
- 188-0293
- Mfr. Part No.:
- B58035U9754M052
- Brand:
- TDK
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 188-0293
- Mfr. Part No.:
- B58035U9754M052
- Brand:
- TDK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK | |
| Capacitance | 750nF | |
| Voltage | 900V dc | |
| Package/Case | FA3 | |
| Mounting Type | Surface Mount | |
| Dielectric | PLZT | |
| Tolerance | ±20% | |
| Dimensions | 7.4 x 9 x 9.1mm | |
| Length | 7.4mm | |
| Automotive Standard | AEC-Q200 | |
| Depth | 9mm | |
| Height | 9.1mm | |
| Series | CeraLink FA | |
| Maximum Operating Temperature | +150°C | |
| Minimum Operating Temperature | -40°C | |
| Terminal Type | Solder | |
Select all | ||
|---|---|---|
Brand TDK | ||
Capacitance 750nF | ||
Voltage 900V dc | ||
Package/Case FA3 | ||
Mounting Type Surface Mount | ||
Dielectric PLZT | ||
Tolerance ±20% | ||
Dimensions 7.4 x 9 x 9.1mm | ||
Length 7.4mm | ||
Automotive Standard AEC-Q200 | ||
Depth 9mm | ||
Height 9.1mm | ||
Series CeraLink FA | ||
Maximum Operating Temperature +150°C | ||
Minimum Operating Temperature -40°C | ||
Terminal Type Solder | ||
High ripple current capability
High temperature robustness
Low equivalent serial inductance (ESL)
Low equivalent serial resistance (ESR)
Low power loss
Low dielectric absorption
Optimized for high frequencies up to several MHz
Increasing capacitance with DC bias up to operating voltage
High capacitance density
Minimized dielectric loss at high temperatures
Suitable for reflow soldering only
Applications
Power converters and inverters
DC link/snubber capacitor for power converters and inverters
