Amphenol Limited, 62 GB, Copper Alloy Straight 3 Way MIL Spec Circular Connector Female, Male Contacts,Shell Size 8,
- RS Stock No.:
- 200-5347
- Mfr. Part No.:
- 62GB-57A08-03PN
- Brand:
- Amphenol Limited
Bulk discount available
Subtotal (1 unit)*
£23.31
(exc. VAT)
£27.97
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 24 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £23.31 |
| 10 + | £21.82 |
*price indicative
- RS Stock No.:
- 200-5347
- Mfr. Part No.:
- 62GB-57A08-03PN
- Brand:
- Amphenol Limited
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Amphenol Limited | |
| Product Type | MIL Spec Circular Connector | |
| Number of Contacts | 3 | |
| Contact Gender | Male | |
| Current | 7.5A | |
| Connector Gender | Female | |
| Voltage | 700V | |
| Shell Size | 8 | |
| Military Standard | MIL-DTL-26482 | |
| Minimum Operating Temperature | -55°C | |
| Mating Type | Bayonet | |
| Termination Type | Crimp | |
| Connector Size | Standard | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | No | |
| Orientation | Straight | |
| Housing Material | Aluminium Alloy | |
| Series | 62 GB | |
| Strain Relief | No | |
| Contact Material | Copper Alloy | |
| Contact Plating | Gold | |
| Select all | ||
|---|---|---|
Brand Amphenol Limited | ||
Product Type MIL Spec Circular Connector | ||
Number of Contacts 3 | ||
Contact Gender Male | ||
Current 7.5A | ||
Connector Gender Female | ||
Voltage 700V | ||
Shell Size 8 | ||
Military Standard MIL-DTL-26482 | ||
Minimum Operating Temperature -55°C | ||
Mating Type Bayonet | ||
Termination Type Crimp | ||
Connector Size Standard | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals No | ||
Orientation Straight | ||
Housing Material Aluminium Alloy | ||
Series 62 GB | ||
Strain Relief No | ||
Contact Material Copper Alloy | ||
Contact Plating Gold | ||
The Amphenol 62GB series connector brings the advantage of keyway orientation to reduce mismating around multiple connectors. They feature aluminium shells with brass or stainless steel options available. A resilient neoprene insulator integrated rear wire sealing grommet guarantees a liquid tight assembly.
Temperature operating range : -55°C to 125°C
Wire gauges and current carrying capabilities : Upto 45A and size 24 to 8 AWG wires
Connectors contacts are gold plated
