Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 174-6550
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Accuracy | ±0.004 mm | |
| Resolution | 0.01 mm | |
| Imperial or Metric | Both | |
| Set Contents | Adjustment Tools, Fitted Case, Mechanical Blade Micrometer, Setting Rod | |
| Maximum Measurement | 25mm | |
| Minimum Measurement | 0mm | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Accuracy ±0.004 mm | ||
Resolution 0.01 mm | ||
Imperial or Metric Both | ||
Set Contents Adjustment Tools, Fitted Case, Mechanical Blade Micrometer, Setting Rod | ||
Maximum Measurement 25mm | ||
Minimum Measurement 0mm | ||
RoHS Status: Not Applicable
- COO (Country of Origin):
- CN
Suitable for groove measurement
Fixed & moving blades ground 0.75mm x 6.5mm
Non-glare satin chrome barrel and sleeve
Models above 25mm supplied with setting standards
Graduations: Metric: .01mm Inch: .001”
Fixed & moving blades ground 0.75mm x 6.5mm
Non-glare satin chrome barrel and sleeve
Models above 25mm supplied with setting standards
Graduations: Metric: .01mm Inch: .001”
