Microchip, 16bit PIC, PIC24FJ Microcontroller, 32MHz, 1.024 MB Flash, 64-Pin TQFP

View all Microcontrollers
Bulk discount available

Subtotal (1 pack of 2 units)*

£8.08

(exc. VAT)

£9.70

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 218 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
2 - 8£4.04£8.08
10 - 22£3.79£7.58
24 - 98£3.56£7.12
100 +£3.40£6.80

*price indicative

Packaging Options:
RS Stock No.:
177-3885
Mfr. Part No.:
PIC24FJ1024GA606-I/PT
Brand:
Microchip
Find similar products by selecting one or more attributes.
Select all

Brand

Microchip

Family Name

PIC24FJ

Package Type

TQFP

Mounting Type

Surface Mount

Pin Count

64

Device Core

PIC

Data Bus Width

16bit

Program Memory Size

1.024 MB

Maximum Frequency

32MHz

RAM Size

32 kB

USB Channels

0

Number of PWM Units

1 x 16 bit

Number of SPI Channels

3

Number of USART Channels

0

Number of CAN Channels

0

Typical Operating Supply Voltage

3.6 (Maximum) V

Number of UART Channels

6

Number of I2C Channels

3

Number of LIN Channels

0

Number of Ethernet Channels

0

Height

1.05mm

Width

10mm

Length

10mm

Dimensions

10 x 10 x 1.05mm

Number of ADC Units

1

Pulse Width Modulation

1 (6 x 16 bit)

Maximum Operating Temperature

+85 °C

Program Memory Type

Flash

Maximum Number of Ethernet Channels

0

ADCs

16 x 12 bit

Number of PCI Channels

0

Instruction Set Architecture

RISC

Minimum Operating Temperature

-40 °C

COO (Country of Origin):
TH
PIC24F 16-bit Microcontroller featuring nanoWatt XLP for eXtreme Low Power consumption. The device includes advanced low power features including a Low Voltage Sleep mode that maintains the device state and RAM with a typical current of 340 nA, and a Vbat pin that automatically transitions to the RTCC to a battery supply when Vdd is removed. The family is also includes a 480 segment LCD Driver with 60 segment x 8 common drive capability. The combination of feature make the part ideally suited to a number of battery powered and general purpose applications

Low Power nanoWatt XLP:
10 nA Deep Sleep mode
400 nA RTCC in Vbat mode
330 nA Low Voltage Sleep mode (RAM retention)
400 nA Real Time Clock & Calendar operation in Sleep modes
270 nA Watch Dog Timer operation in Deep Sleep modes
150 uA/MHz Run mode
Power Modes: Run, Doze, Idle, Sleep, Low Voltage Sleep, Deep Sleep, Vbat
Multiple, Switchable Clock Modes for Optimum Performance and Power Management
System Supervisors: Low Power BOR, WDT
