ABB, Formula DSA, 1SDA06 Molded Case Circuit Breaker 1-Pole 80A, Breaking Capacity 25 kA, Fixed
- RS Stock No.:
- 237-6138
- Mfr. Part No.:
- 1SDA066693R1
- Brand:
- ABB
Subtotal (1 unit)*
£118.98
(exc. VAT)
£142.78
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 15 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £118.98 |
*price indicative
- RS Stock No.:
- 237-6138
- Mfr. Part No.:
- 1SDA066693R1
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Range | Formula DSA | |
| Product Type | Molded Case Circuit Breaker | |
| Series | 1SDA06 | |
| Number of Poles | 1 | |
| Current Rating | 80A | |
| Breaking Capacity | 25kA | |
| Rated AC Voltage | 415V ac | |
| Mount Type | Fixed | |
| Rated DC Voltage | 125V dc | |
| Terminal Type | Front | |
| Height | 130mm | |
| Width | 25.4mm | |
| Standards/Approvals | CE, IEC | |
| Depth | 60mm | |
| Tripping Mechanism | Thermal Magnetic | |
| Reset Actuator Type | Lever | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Range Formula DSA | ||
Product Type Molded Case Circuit Breaker | ||
Series 1SDA06 | ||
Number of Poles 1 | ||
Current Rating 80A | ||
Breaking Capacity 25kA | ||
Rated AC Voltage 415V ac | ||
Mount Type Fixed | ||
Rated DC Voltage 125V dc | ||
Terminal Type Front | ||
Height 130mm | ||
Width 25.4mm | ||
Standards/Approvals CE, IEC | ||
Depth 60mm | ||
Tripping Mechanism Thermal Magnetic | ||
Reset Actuator Type Lever | ||
- COO (Country of Origin):
- IT
The ABB A1N 125 fixed single-pole circuit breaker has front terminals and thermomagnetic release. It Is rated for 415 V AC and 125 V DC operational voltage and 80 A current.
125 A rated uninterrupted current (Iu)
Rated for 6 kV withstand voltage (Uimp)
