Schneider Electric, ComPact, NSXm Molded Case Circuit Breaker 4-Pole 32 A, Breaking Capacity 16 kA, DIN Rail
- RS Stock No.:
- 178-8097
- Mfr. Part No.:
- LV426162
- Brand:
- Schneider Electric
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 178-8097
- Mfr. Part No.:
- LV426162
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Range | ComPact | |
| Product Type | Molded Case Circuit Breaker | |
| Series | NSXm | |
| Number of Poles | 4 | |
| Current Rating | 32 A | |
| Breaking Capacity | 16kA | |
| Mount Type | DIN Rail | |
| Rated AC Voltage | 690 V ac | |
| Mount Hole Size | 4.5 mm | |
| Terminal Type | Screw | |
| Depth | 137mm | |
| Standards/Approvals | CE, CCC, EAC, EN, IEC, RoHS | |
| Width | 80 mm | |
| Height | 137mm | |
| Better World Product | Yes | |
| Tripping Characteristics | Type D | |
| Reset Actuator Type | Toggle Switch | |
| Tripping Mechanism | Thermal Magnetic | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Range ComPact | ||
Product Type Molded Case Circuit Breaker | ||
Series NSXm | ||
Number of Poles 4 | ||
Current Rating 32 A | ||
Breaking Capacity 16kA | ||
Mount Type DIN Rail | ||
Rated AC Voltage 690 V ac | ||
Mount Hole Size 4.5 mm | ||
Terminal Type Screw | ||
Depth 137mm | ||
Standards/Approvals CE, CCC, EAC, EN, IEC, RoHS | ||
Width 80 mm | ||
Height 137mm | ||
Better World Product Yes | ||
Tripping Characteristics Type D | ||
Reset Actuator Type Toggle Switch | ||
Tripping Mechanism Thermal Magnetic | ||
Compact Nsxm Is The Smallest Size Molded Case Circuit Breaker (MCCB) In The Compact Nsx Range. With Its Convenient Design, It Can Easily Accommodate Applications From 16 To 160 A. Available With Integrated Earth Leakage Protection.
Circuit Breaker Compact Nsxm 32a 4p 16ka At 380/415v Compression Lug
