Schneider Electric, Linergy, TR Molded Case Circuit Breaker 2-Pole 24 A, Clip-on
- RS Stock No.:
- 658-887
- Mfr. Part No.:
- NSYTRP22AR
- Brand:
- Schneider Electric
Subtotal (1 pack of 50 units)*
£389.77
(exc. VAT)
£467.72
(inc. VAT)
FREE delivery for orders over £50.00
Stocked by manufacturer
- Ready to ship from 24 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £389.77 | £7.795 |
*price indicative
- RS Stock No.:
- 658-887
- Mfr. Part No.:
- NSYTRP22AR
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Product Type | Molded Case Circuit Breaker | |
| Range | Linergy | |
| Series | TR | |
| Number of Poles | 2 | |
| Current Rating | 24 A | |
| Mount Type | Clip-on | |
| Rated AC Voltage | 800 V ac | |
| Terminal Type | Push-in | |
| Width | 5.2 mm | |
| Standards/Approvals | CSA, EN/IEC 60947-7-1, UL, VDE | |
| Height | 36.5mm | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Product Type Molded Case Circuit Breaker | ||
Range Linergy | ||
Series TR | ||
Number of Poles 2 | ||
Current Rating 24 A | ||
Mount Type Clip-on | ||
Rated AC Voltage 800 V ac | ||
Terminal Type Push-in | ||
Width 5.2 mm | ||
Standards/Approvals CSA, EN/IEC 60947-7-1, UL, VDE | ||
Height 36.5mm | ||
- COO (Country of Origin):
- CN
The Schneider Electric Linergy TR terminal block is a push-in type, feed-through, with 2 points, and a nominal cross section of 2.5 mm². It is orange in color, 48.5 mm in length, and comes in a set of 50. The terminal block is designed for clip-on mounting.
Polyamide 6/6 insulating case
Copper alloy connector and screw
Copper alloy communing link
Chromium-nickel steel spring
