Eaton, NZM, NZM Molded Case Circuit Breaker 3-Pole 70 A, Breaking Capacity 18.5 kA, Fixed
- RS Stock No.:
- 231-999
- Mfr. Part No.:
- 107620 NZMB2-AF70-BT-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£652.54
(exc. VAT)
£783.05
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 25 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £652.54 |
*price indicative
- RS Stock No.:
- 231-999
- Mfr. Part No.:
- 107620 NZMB2-AF70-BT-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Molded Case Circuit Breaker | |
| Range | NZM | |
| Series | NZM | |
| Number of Poles | 3 | |
| Current Rating | 70 A | |
| Breaking Capacity | 18.5kA | |
| Rated AC Voltage | 440 V ac | |
| Mount Type | Fixed | |
| Terminal Type | Box | |
| Standards/Approvals | IEC 60947-2 UL CSA CSA (File No. 22086) CE marking CSA-C22.2 No. 5-09 UL (File No. E31593) IEC/EN 60947 CSA (Class No. 1432-01) Specially designed for North America UL/CSA UL 489 IEC UL (Category Control Number DIVQ) | |
| Width | 105 mm | |
| Depth | 149mm | |
| Height | 195mm | |
| Reset Actuator Type | Rocker Lever | |
| Break Time | 10 ms | |
| Tripping Characteristics | Thermomagnetic | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Molded Case Circuit Breaker | ||
Range NZM | ||
Series NZM | ||
Number of Poles 3 | ||
Current Rating 70 A | ||
Breaking Capacity 18.5kA | ||
Rated AC Voltage 440 V ac | ||
Mount Type Fixed | ||
Terminal Type Box | ||
Standards/Approvals IEC 60947-2 UL CSA CSA (File No. 22086) CE marking CSA-C22.2 No. 5-09 UL (File No. E31593) IEC/EN 60947 CSA (Class No. 1432-01) Specially designed for North America UL/CSA UL 489 IEC UL (Category Control Number DIVQ) | ||
Width 105 mm | ||
Depth 149mm | ||
Height 195mm | ||
Reset Actuator Type Rocker Lever | ||
Break Time 10 ms | ||
Tripping Characteristics Thermomagnetic | ||
- COO (Country of Origin):
- RO
The Eaton Molded Case Circuit Breaker offers robust protection and reliability for your electrical systems. Designed specifically for the North American market, this 3-pole, ensuring safety and compliance with rigorous international standards. The thermo-magnetic release system ensures precise protection against short circuits and overloads, while its exceptional breaking capacity of up to 30 kA at 230 V and 25 kA at 400/415 V provides peace of mind under demanding conditions. With an IP20 rating for basic protection and options for enhanced enclosure integrity, this circuit breaker is well-suited for a variety of installation environments, delivering a blend of performance and adaptability for your electrical needs.
Comprehensive compliance with IEC and UL standards enhances safety assurance
Flexible mounting options including fixed and DIN rail solutions
Easy integration with existing systems and configurations
Minimal maintenance required due to high durability and engineering excellence
Designed for efficient heat dissipation to protect against overheating
