Lovato ModuLo P1MB MCB, 2P, 6A Curve B, 230V AC, 80V DC, 10 kA Breaking Capacity
- RS Stock No.:
- 825-5674
- Mfr. Part No.:
- P1MB2PB06
- Brand:
- Lovato
36 In stock - FREE next working day delivery available
Added
Price Each
£40.02
(exc. VAT)
£48.02
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £40.02 |
| 10 - 14 | £38.01 |
| 15 + | £36.74 |
- RS Stock No.:
- 825-5674
- Mfr. Part No.:
- P1MB2PB06
- Brand:
- Lovato
Technical Reference
Legislation and Compliance
RoHS Status: Exempt
- COO (Country of Origin):
- IT
Product Details
P1MB MCBs 2P
Miniature Circuit Breakers up to 63A with positive indication by flag window
Ratings 1 to 63A
Tripping characteristics B, C and D
Rated insulation voltagei: 440V
Rated impulse withstand voltage: 4kV
Rated operating voltage: 230/400VAC
DIN rail mounting
Add-on blocks available
Tripping characteristics B, C and D
Rated insulation voltagei: 440V
Rated impulse withstand voltage: 4kV
Rated operating voltage: 230/400VAC
DIN rail mounting
Add-on blocks available
Lovato MCBs
Specifications
Attribute | Value |
|---|---|
| Number of Poles | 2P |
| Current Rating | 6A |
| Tripping Characteristics | Type B |
| Rated AC Voltage | 230 V, 400V |
| Rated DC Voltage | 80V |
| Breaking Capacity at Maximum Voltage Rating | 10 kA |
| Range | ModuLo |
| Series | P1MB |
| Circuit Breaker Type | MCB |
| Width | 36mm |
| Length | 86.5mm |
| Mounting Style | DIN Rail Mount |
| Depth | 80mm |
