Lovato ModuLo P1MB MCB, 1P, 4A Curve B, 230V AC, 60V DC, 10 kA Breaking Capacity
- RS Stock No.:
- 825-5542
- Mfr. Part No.:
- P1MB1PB04
- Brand:
- Lovato
1 In stock - FREE next working day delivery available
Added
Price Each
£21.75
(exc. VAT)
£26.10
(inc. VAT)
| Units | Per unit |
| 1 - 14 | £21.75 |
| 15 - 24 | £20.67 |
| 25 + | £19.94 |
- RS Stock No.:
- 825-5542
- Mfr. Part No.:
- P1MB1PB04
- Brand:
- Lovato
Technical Reference
Legislation and Compliance
RoHS Status: Exempt
- COO (Country of Origin):
- IT
Product Details
P1MB MCBs 1P
Miniature Circuit Breakers up to 63A with positive indication by flag window
Ratings 1 to 63A
Tripping characteristics B, C and D
Rated insulation voltage: 440V
Rated impulse withstand voltage: 4kV
Rated operating voltage: 230/400VAC
DIN rail mounting
Add-on blocks available
Tripping characteristics B, C and D
Rated insulation voltage: 440V
Rated impulse withstand voltage: 4kV
Rated operating voltage: 230/400VAC
DIN rail mounting
Add-on blocks available
Lovato MCBs
Specifications
Attribute | Value |
|---|---|
| Number of Poles | 1P |
| Current Rating | 4A |
| Tripping Characteristics | Type B |
| Rated AC Voltage | 230V |
| Rated DC Voltage | 60V |
| Breaking Capacity at Maximum Voltage Rating | 10 kA |
| Range | ModuLo |
| Series | P1MB |
| Circuit Breaker Type | MCB |
| Width | 18mm |
| Length | 86.5mm |
| Mounting Style | DIN Rail Mount |
| Depth | 80mm |
