Eaton Moeller Eaton Moeller Miniature Circuit Breaker, 1-Pole, 5 A, Type D, 240 V AC, 48 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 270-5265
- Mfr. Part No.:
- 278577 FAZ-D5/1
- Brand:
- Eaton
Subtotal (1 unit)*
£49.07
(exc. VAT)
£58.88
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 39 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £49.07 |
*price indicative
- RS Stock No.:
- 270-5265
- Mfr. Part No.:
- 278577 FAZ-D5/1
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 1 | |
| Current Rating | 5 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 240 V | |
| Rated DC Voltage | 48 V | |
| Breaking Capacity | 15kA | |
| Range | Moeller | |
| Series | Eaton Moeller | |
| IP Rating | IP20 | |
| Width | 17.7 mm | |
| Height | 75.5mm | |
| Depth | 80mm | |
| Standards/Approvals | CE, UL (File No. E177451), CSA-C22.2 No. 235, CSA (Class No. 3215-30), CSA (File No. 204453), EN45545-2, IEC 61373, IEC/EN 60898, IEC/EN 60947-2, RoHS, UL 1077, UL (Category Control Number QVNU2,QVNU8), UL CSA09 | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 1 | ||
Current Rating 5 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 240 V | ||
Rated DC Voltage 48 V | ||
Breaking Capacity 15kA | ||
Range Moeller | ||
Series Eaton Moeller | ||
IP Rating IP20 | ||
Width 17.7 mm | ||
Height 75.5mm | ||
Depth 80mm | ||
Standards/Approvals CE, UL (File No. E177451), CSA-C22.2 No. 235, CSA (Class No. 3215-30), CSA (File No. 204453), EN45545-2, IEC 61373, IEC/EN 60898, IEC/EN 60947-2, RoHS, UL 1077, UL (Category Control Number QVNU2,QVNU8), UL CSA09 | ||
- COO (Country of Origin):
- RO
The Eaton Moeller series xEffect FAZ miniature circuit breaker for industrial and advanced commercial applications, that has built in depth 70.5 mm.
Overvoltage category III
Pollution degree 2
