ABB System Pro M Compact S200 Miniature Circuit Breaker, 3-Pole, 16 A, Type Z, 440 V ac AC, 110 V DC, 6 kA Breaking
- RS Stock No.:
- 237-3293
- Mfr. Part No.:
- 2CDS253103R0468
- Brand:
- ABB
Subtotal (1 unit)*
£146.09
(exc. VAT)
£175.31
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 19 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £146.09 |
*price indicative
- RS Stock No.:
- 237-3293
- Mfr. Part No.:
- 2CDS253103R0468
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 3 | |
| Current Rating | 16 A | |
| Tripping Characteristics | Type Z | |
| Rated AC Voltage | 440 V ac | |
| Rated DC Voltage | 110 V | |
| Mount Type | DIN Rail | |
| Breaking Capacity | 6kA | |
| Range | System Pro M Compact | |
| Series | S200 | |
| Terminal Type | Screw | |
| IP Rating | IP40, IP20 | |
| Width | 70 mm | |
| Height | 88mm | |
| Depth | 69mm | |
| Standards/Approvals | IEC/EN 60947-2 UL 1077 | |
| Tripping Mechanism | Thermal, Electromechanic | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 3 | ||
Current Rating 16 A | ||
Tripping Characteristics Type Z | ||
Rated AC Voltage 440 V ac | ||
Rated DC Voltage 110 V | ||
Mount Type DIN Rail | ||
Breaking Capacity 6kA | ||
Range System Pro M Compact | ||
Series S200 | ||
Terminal Type Screw | ||
IP Rating IP40, IP20 | ||
Width 70 mm | ||
Height 88mm | ||
Depth 69mm | ||
Standards/Approvals IEC/EN 60947-2 UL 1077 | ||
Tripping Mechanism Thermal, Electromechanic | ||
- COO (Country of Origin):
- DE
The ABB S203 series is the mini circuit breaker with two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electro mechanic tripping mechanism for short circuit protection. This MCB have type Z characteristics.
IP degree of protection is the IP20
Ambient air temperature for operation -25 to +55 °C
