ABB System Pro M Compact S200 Miniature Circuit Breaker, 1-Pole, 20A, Type D, 400V ac AC, 12 V DC, 6 kA Breaking

RS Stock No.:: 237-3198
Mfr. Part No.:: 2CDS251103R0201
Brand:: ABB

ABB System Pro M Compact S200 Miniature Circuit Breaker, 1-Pole, 20A, Type D, 400V ac AC, 12 V DC, 6 kA Breaking

View all MCBs

Subtotal (1 unit)*

£85.86

(exc. VAT)

£103.03

(inc. VAT)

FREE delivery for orders over £60.00

Stocked by manufacturer

Ready to ship from 17 July 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£85.86

*price indicative

Our Better World range features products that make it easy for you to make a greener product choice you can trust.

Click here to find out more.

RS Stock No.:: 237-3198
Mfr. Part No.:: 2CDS251103R0201
Brand:: ABB

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Product Type	Miniature Circuit Breaker
	Number of Poles	1
	Current Rating	20A
	Tripping Characteristics	Type D
	Rated AC Voltage	400V ac
	Rated DC Voltage	12V
	Breaking Capacity	6kA
	Mount Type	DIN Rail
	Range	System Pro M Compact
	Series	S200
	Terminal Type	Screw
	IP Rating	IP20, IP40
	Standards/Approvals	IEC/EN 60898-1, IEC/EN 60947-2
	Width	35mm
	Height	88mm
	Depth	69mm
	Better World Product	Yes
	Better World Claim	Designed for Disassembly
	Tripping Mechanism	Thermomagnetic, Electromagnetic
	Reset Actuator Type	Toggle Switch

	Select all
	Brand ABB
	Product Type Miniature Circuit Breaker
	Number of Poles 1
	Current Rating 20A
	Tripping Characteristics Type D
	Rated AC Voltage 400V ac
	Rated DC Voltage 12V
	Breaking Capacity 6kA
	Mount Type DIN Rail
	Range System Pro M Compact
	Series S200
	Terminal Type Screw
	IP Rating IP20, IP40
	Standards/Approvals IEC/EN 60898-1, IEC/EN 60947-2
	Width 35mm
	Height 88mm
	Depth 69mm
	Better World Product Yes
	Better World Claim Designed for Disassembly
	Tripping Mechanism Thermomagnetic, Electromagnetic
	Reset Actuator Type Toggle Switch

COO (Country of Origin):: DE

ABB S200 Series MCB, 20A Current Rating, Type D Tripping Characteristics - 2CDS251103R0201

This miniature circuit breaker is a Compact 1+N type device designed to protect electrical circuits. Manufactured by ABB, it features a current rating of 20A and offers a tripping characteristic of Type D. Its dimensions are 35mm in width, 69mm in length, and 69mm in depth. The product is suitable for installation on a DIN rail, making it versatile for various settings.

Features & Benefits

• Provides thermal and electromechanical tripping mechanisms
• Ensures overload protection with delayed response
• Capable of withstanding a breaking capacity of 10kA
• Designed for ease of installation on DIN rail systems
• Complies with relevant IEC and BS standards for safety

Applications

• Used in commercial settings for circuit protection
• Ideal for residential installations requiring safety devices
• Applicable in automation and electrical systems for reliable performance
• Suitable for mechanical industries needing efficient overload protection

What mechanisms ensure the effectiveness of this circuit breaker in safeguarding systems?

The device employs both thermal tripping for overload protection and an electromechanical mechanism to respond to short circuits, ensuring comprehensive safety for electrical systems.

How does the Compact size impact installation and functionality?

Its Compact design allows for efficient use of space on DIN rail mounts, facilitating seamless integration into standard electrical panels without occupying excessive space.

What are the environmental considerations associated with this circuit breaker?

It is designed with environmental sustainability in mind, following circular design principles and being recyclable, which reduces the product's ecological footprint at the end of its life cycle.
