MPN

Eaton xEffect MCB, 3+N, 1A Curve B

RS Stock No.:: 230-0871
Mfr. Part No.:: 177446 FAZ6-B1/3N
Brand:: Eaton

Subtotal (1 unit)*

£94.15

(exc. VAT)

£112.98

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

2 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£94.15

*price indicative

RS Stock No.:: 230-0871
Mfr. Part No.:: 177446 FAZ6-B1/3N
Brand:: Eaton

Eaton MCB, 1A Current Rating, 415V Rated AC Voltage - 177446 FAZ6-B1/3N

This miniature circuit breaker (MCB) falls under Eaton's xEffect range and offers precise electrical circuit protection. Rated at 1A and featuring a 3-pole plus neutral configuration, it is designed for robust performance in various electrical applications. Measuring 72mm in width and 72.6mm in length, this DIN rail mounted MCB is ideal for ensuring safe electrical management.

Features & Benefits

• Type B characteristic allows for specific targeted tripping
• 10kA breaking capacity ensures effective fault management
• Rated AC voltage at 415V supports diverse electrical systems
• Toggle switch reset actuator provides ease of operation
• Designed for DIN rail mounting simplifies installation and integration
• Reliable operation across a wide temperature range of -40°C to 75°C

Applications

• Utilised in industrial automation systems
• Suitable for commercial electrical installations
• Ideal for protecting lighting and power distribution circuits
• Employed in control panels for enhanced safety
• Commonly used in mechanical systems requiring circuit integrity

What are the implications of the 10kA breaking capacity for fault protection?

The 10kA breaking capacity allows the device to effectively interrupt high short-circuit currents, minimising potential damage to connected equipment and enhancing overall system safety.

How does the toggle switch reset actuator function improve usability?

The toggle switch provides straightforward manual resetting after a trip, allowing for quick restoration of service without any additional tools, which is beneficial in time-sensitive environments.

Can this MCB operate in extreme temperatures?

Yes, it is rated for ambient temperatures ranging from -40°C to 75°C, making it suitable for use in a variety of challenging environments without compromising performance.

What are the installation requirements for this circuit breaker?

This MCB is designed for DIN rail mounting, simplifying the installation process in standard electrical panels and ensuring secure integration in electrical systems.

What advantages does a Type B characteristic offer for circuit protection?

A Type B characteristic is ideal for circuits with resistive loads, offering a balance between protection and sensitivity that reduces nuisance tripping while safeguarding equipment from overloads.

Note

Eaton formerly known as Moeller

Find similar products by selecting one or more attributes.

Be the first to know about our latest products and services

Join our mailing list today:

The personal information you provide to us when signing up to the mailing list will be processed in line with our privacy policy.

Select all	Attribute	Value
	Brand	Eaton
	Number of Poles	3+N
	Current Rating	1A
	Tripping Characteristics	Type B
	Range	xEffect
	Mounting Style	DIN Rail Mount
	Model Number	FAZ6-B1/3N

	Select all
	Brand Eaton
	Number of Poles 3+N
	Current Rating 1A
	Tripping Characteristics Type B
	Range xEffect
	Mounting Style DIN Rail Mount
	Model Number FAZ6-B1/3N
