Schneider Electric Multi9 N40N Miniature Circuit Breaker, 3-Pole, 16A, Type C, 415V ac AC, 10 kA Breaking Capacity
- RS Stock No.:
- 214-2094
- Mfr. Part No.:
- M9P22716
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£206.25
(exc. VAT)
£247.50
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 2 unit(s) shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £206.25 |
*price indicative
- RS Stock No.:
- 214-2094
- Mfr. Part No.:
- M9P22716
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 16A | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 415V ac | |
| Breaking Capacity | 10kA | |
| Mount Type | DIN Rail | |
| Range | Multi9 | |
| Series | N40N | |
| Terminal Type | Tunnel | |
| IP Rating | IP40, IP20 | |
| Standards/Approvals | EN/IEC 60947-2 | |
| Depth | 72mm | |
| Height | 81mm | |
| Width | 54mm | |
| Tripping Mechanism | Thermal Magnetic | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 16A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 415V ac | ||
Breaking Capacity 10kA | ||
Mount Type DIN Rail | ||
Range Multi9 | ||
Series N40N | ||
Terminal Type Tunnel | ||
IP Rating IP40, IP20 | ||
Standards/Approvals EN/IEC 60947-2 | ||
Depth 72mm | ||
Height 81mm | ||
Width 54mm | ||
Tripping Mechanism Thermal Magnetic | ||
- COO (Country of Origin):
- HU
The Schneider Electric N40N series have MCB having 16 amp rated operating current and its used for the distribution application. This MCB have thermal magnetic trip unit technology with C curve code. This MCB have toggle control type with din rail mounting.
IP degree of protection is IP20 and IP40
Ambient air temperature for operation is -25 to 70 °C
