ABB S200C MCB, 3P, 20A Curve B, 415V AC, 6 kA Breaking Capacity
- RS Stock No.:
- 212-1649
- Mfr. Part No.:
- 2CDS253280R0205
- Brand:
- ABB
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 212-1649
- Mfr. Part No.:
- 2CDS253280R0205
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | ABB | |
Number of Poles | 3 | |
Current Rating | 20A | |
Tripping Characteristics | Type B | |
Rated AC Voltage | 415V | |
Breaking Capacity at Maximum Voltage Rating | 6 kA | |
Series | S200C | |
Circuit Breaker Type | MCB | |
Length | 70mm | |
Width | 36mm | |
Mounting Style | DIN Rail Mount | |
Depth | 70mm | |
Model Number | S203C-B20 | |
Reset Actuator Type | Toggle Switch | |
Special Features | Short Circuit Protection | |
Select all | ||
---|---|---|
Brand ABB | ||
Number of Poles 3 | ||
Current Rating 20A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 415V | ||
Breaking Capacity at Maximum Voltage Rating 6 kA | ||
Series S200C | ||
Circuit Breaker Type MCB | ||
Length 70mm | ||
Width 36mm | ||
Mounting Style DIN Rail Mount | ||
Depth 70mm | ||
Model Number S203C-B20 | ||
Reset Actuator Type Toggle Switch | ||
Special Features Short Circuit Protection | ||
- COO (Country of Origin):
- PL
ABB S200C Series MCB, 25A Current Rating, DIN Rail Mounting Style - 2CDS253280R0205
This MCB by ABB is a reliable 20A circuit breaker with a breaking capacity of 6kA and tripping characteristics of Type B. It is designed for efficient circuit protection in various applications, ensuring safety and reliability.
Features & Benefits
• Compact design for saving space in installations
• Easy to install with flexible supply options
• High performance clips for easy mounting and dismounting
• Easy mounting on DIN rail for convenient installation
• Dedicated space for labels for clear identification
• Indication of contact status for added security
• Laser printed information for easy identification
• Compatibility with signal and auxiliary contacts
• Easy to install with flexible supply options
• High performance clips for easy mounting and dismounting
• Easy mounting on DIN rail for convenient installation
• Dedicated space for labels for clear identification
• Indication of contact status for added security
• Laser printed information for easy identification
• Compatibility with signal and auxiliary contacts
Applications
• Residential, commercial, marine, and traction segments
• Protection and control of circuits against overloads and short-circuits
• Wide range of rated current variants to suit different applications
• Protection and control of circuits against overloads and short-circuits
• Wide range of rated current variants to suit different applications
Can it save space in installations?
Yes, the compact design saves up to 50% more space.
What applications is it suitable for?
It is suitable for residential, commercial, marine, and traction segments.
Is it easy to install?
Yes, it is easy to install with flexible supply options.
What is the breaking capacity of this MCB?
The breaking capacity is 6kA for reliable circuit protection.
Can I easily identify the protected lines?
Yes, there is a dedicated space for labels to ensure clear identification.
