Schneider Electric Multi9 Multi9 Miniature Circuit Breaker, 3-Pole, 25A, Type D, 14 kA Breaking Capacity
- RS Stock No.:
- 211-2409
- Mfr. Part No.:
- M9F23425
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£201.16
(exc. VAT)
£241.39
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 2 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £201.16 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 211-2409
- Mfr. Part No.:
- M9F23425
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 25A | |
| Tripping Characteristics | Type D | |
| Mount Type | DIN Rail | |
| Breaking Capacity | 14kA | |
| Range | Multi9 | |
| Series | Multi9 | |
| Terminal Type | Tunnel Terminal | |
| IP Rating | IP20, IP40 | |
| Depth | 72mm | |
| Height | 81mm | |
| Width | 54mm | |
| Standards/Approvals | CCC, CSA, CSA C22.2 No 235, EN/IEC 60947-2, GB 14048.2, IEC, UL 1077, UR | |
| Better World Product | Yes | |
| Tripping Mechanism | Thermal Magnetic | |
| Reset Actuator Type | Toggle Switch | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 25A | ||
Tripping Characteristics Type D | ||
Mount Type DIN Rail | ||
Breaking Capacity 14kA | ||
Range Multi9 | ||
Series Multi9 | ||
Terminal Type Tunnel Terminal | ||
IP Rating IP20, IP40 | ||
Depth 72mm | ||
Height 81mm | ||
Width 54mm | ||
Standards/Approvals CCC, CSA, CSA C22.2 No 235, EN/IEC 60947-2, GB 14048.2, IEC, UL 1077, UR | ||
Better World Product Yes | ||
Tripping Mechanism Thermal Magnetic | ||
Reset Actuator Type Toggle Switch | ||
- COO (Country of Origin):
- FR
The Schneider Electric's C60SP Series are multi-standard miniature circuit breakers and supplementary protection as defined by UL 1077. It has function such as tripping and electrical fault indication by the addition of auxiliaries.
Circuit protection against short-circuit currents
Circuit protection against overload currents
