Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 2.5 A, Type B, 230 V ac AC, 7.5 kA Breaking Capacity
- RS Stock No.:
- 259-581
- Mfr. Part No.:
- 278637 FAZ-B2,5/1N
- Brand:
- Eaton
Subtotal (1 unit)*
£58.54
(exc. VAT)
£70.25
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 20 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £58.54 |
*price indicative
- RS Stock No.:
- 259-581
- Mfr. Part No.:
- 278637 FAZ-B2,5/1N
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 1 | |
| Current Rating | 2.5 A | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 230 V ac | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 7.5kA | |
| Range | xEffect | |
| Series | FAZ | |
| IP Rating | IP20 | |
| Standards/Approvals | UL, IEC/EN 60898, IEC 61373, EN 63000:2018, EN45545-2, EAN, CSA, RoHS, IEC/EN 60947-2 | |
| Height | 75.5mm | |
| Width | 36 mm | |
| Depth | 80mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 1 | ||
Current Rating 2.5 A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 230 V ac | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 7.5kA | ||
Range xEffect | ||
Series FAZ | ||
IP Rating IP20 | ||
Standards/Approvals UL, IEC/EN 60898, IEC 61373, EN 63000:2018, EN45545-2, EAN, CSA, RoHS, IEC/EN 60947-2 | ||
Height 75.5mm | ||
Width 36 mm | ||
Depth 80mm | ||
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series xEffect offers exceptional protection for industrial and advanced commercial applications. Designed for reliability and efficiency, it features a single pole + N configuration and a tripping characteristic of B, tailored for sensitive equipment. This device not only ensures superior electrical safety but also meets stringent compliance standards, making it ideal for demanding environments. With a rated current of 2.5 A, this product boasts impressive breaking capacity and is compatible with various conductor sizes.
Meets RoHS compliance ensuring minimal environmental impact
Provides effective protection against electrical overloads
Rated for an ambient operating temperature range ensuring versatility
Offers a breaking capacity designed to handle high fault currents
Integrated features promote efficient heat management
Compatible with standard wiring practices simplifying integration
Durable construction tailored for demanding operational environments
