Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 3.5 A, Type B, 230 V ac AC, 10 kA Breaking Capacity
- RS Stock No.:
- 256-928
- Mfr. Part No.:
- 278639 FAZ-B3,5/1N
- Brand:
- Eaton
Subtotal (1 unit)*
£58.54
(exc. VAT)
£70.25
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £58.54 |
*price indicative
- RS Stock No.:
- 256-928
- Mfr. Part No.:
- 278639 FAZ-B3,5/1N
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 1 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 3.5 A | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 230 V ac | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 10kA | |
| Range | xEffect | |
| Series | FAZ | |
| IP Rating | IP20 | |
| Height | 75.5mm | |
| Width | 36 mm | |
| Standards/Approvals | UL, RoHS, IEC/EN 60947-2, IEC/EN 60898, IEC 61373, EN 63000:2018, EN45545-2, EAN, CSA | |
| Depth | 80mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 1 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 3.5 A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 230 V ac | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 10kA | ||
Range xEffect | ||
Series FAZ | ||
IP Rating IP20 | ||
Height 75.5mm | ||
Width 36 mm | ||
Standards/Approvals UL, RoHS, IEC/EN 60947-2, IEC/EN 60898, IEC 61373, EN 63000:2018, EN45545-2, EAN, CSA | ||
Depth 80mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series xEffect is designed for demanding industrial and advanced commercial applications. It boasts a rated current of 3.5 A and a remarkable rated switching capacity of 15 kA, making it suitable for a wide variety of electrical installations. Its compact design with a depth of just 70.5 mm allows for easy integration into existing systems, while the robust construction meets the highest safety standards. The device complies with RoHS regulations and has been certified to EN45545 2, underscoring its commitment to safety and environmental responsibility.
Designed for both industrial and advanced commercial applications
Offers superior protection with a B tripping characteristic
Compact dimensions facilitate space saving installations
Highly rated switching capacity enhances system reliability
Robust construction meets strict safety standards
