Eaton xEffect FAZ MCB, 1+N, 4A Curve C, 240V AC, 60V DC, 7.5 kA Breaking Capacity
- RS Stock No.:
- 255-795
- Mfr. Part No.:
- 241025 FAZT-C4/1N
- Brand:
- Eaton
Subtotal (1 unit)*
£80.70
(exc. VAT)
£96.84
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £80.70 |
*price indicative
- RS Stock No.:
- 255-795
- Mfr. Part No.:
- 241025 FAZT-C4/1N
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Eaton | |
Number of Poles | 1+N | |
Current Rating | 4A | |
Tripping Characteristics | Type C | |
Rated AC Voltage | 240V | |
Rated DC Voltage | 60V | |
Breaking Capacity at Maximum Voltage Rating | 7.5 kA | |
Range | xEffect | |
Series | FAZ | |
Select all | ||
---|---|---|
Brand Eaton | ||
Number of Poles 1+N | ||
Current Rating 4A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 240V | ||
Rated DC Voltage 60V | ||
Breaking Capacity at Maximum Voltage Rating 7.5 kA | ||
Range xEffect | ||
Series FAZ | ||
- COO (Country of Origin):
- RO
The Eaton miniature circuit breaker (MCB) from The Eaton Moeller series xEffect FAZ T is designed to provide reliable overcurrent protection in diverse industrial and commercial applications. Built with precision engineering, it features a one pole plus neutral configuration and a tripping characteristic of C, making it suitable for applications where surge currents are present. The product's robust specifications ensure it can handle a rated current of 4 A, catering adeptly to modern electrical demands while maintaining safety standards. With dimensions of 80 mm in length and 36 mm in width, it can be conveniently mounted using a quick attachment method on a top hat rail. The device is also compliant with various international standards, guaranteeing quality performance across installations.
Designed for industrial and advanced commercial applications
Conforms to RoHS regulations enhancing environmental safety
Offers finger and hand touch safety for users
Efficient heat dissipation with current dependent capabilities
Sturdy build qualified for up to 10000 mechanical operations
Provides ease of installation with multiple latch positions
Suitable for use in ambient temperatures ranging from 25 °C to 75 °C
Includes twin purpose terminals for versatile connectivity
Conforms to RoHS regulations enhancing environmental safety
Offers finger and hand touch safety for users
Efficient heat dissipation with current dependent capabilities
Sturdy build qualified for up to 10000 mechanical operations
Provides ease of installation with multiple latch positions
Suitable for use in ambient temperatures ranging from 25 °C to 75 °C
Includes twin purpose terminals for versatile connectivity
