Eaton xEffect FAZ Miniature Circuit Breaker, 2-Pole, 3 A, Type B, 440 V ac AC, 60 V DC, 7.5 kA Breaking Capacity
- RS Stock No.:
- 254-987
- Mfr. Part No.:
- 240822 FAZT-B3/2
- Brand:
- Eaton
Subtotal (1 unit)*
£128.23
(exc. VAT)
£153.88
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 20 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £128.23 |
*price indicative
- RS Stock No.:
- 254-987
- Mfr. Part No.:
- 240822 FAZT-B3/2
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 2 | |
| Current Rating | 3 A | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 440 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 7.5kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Width | 36.45 mm | |
| Height | 75.5mm | |
| Standards/Approvals | EN45545-2, IEC 61373, IEC/EN 60947-2, RoHS conform | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 2 | ||
Current Rating 3 A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 440 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 7.5kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Width 36.45 mm | ||
Height 75.5mm | ||
Standards/Approvals EN45545-2, IEC 61373, IEC/EN 60947-2, RoHS conform | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Moeller series xEffect FAZ T miniature circuit breaker (MCB) embodies cutting edge engineering, designed to provide exceptional protection for industrial and advanced commercial applications. With a robust two pole configuration and a tripping characteristic of B, this MCB effectively safeguards electrical circuits from overloads and short circuits. Rated for a current of 3 A, it boasts an operational voltage capacity of 440 VAC, ensuring reliability in demanding environments. The compact design facilitates straightforward installation on top hat rails, maximising space efficiency. Enhanced with several compliance certifications, including RoHS and IEC standards, this device not only ensures optimal performance but also upholds environmental responsibility. The FAZ T series stands as a testament to Eaton's commitment to quality and innovation in electrical safety solutions.
Designed for reliable protection in commercial and industrial settings
Tripping characteristic optimised for quick response to overloads
Easy installation with quick attachment features for top hat rail fitting
Offers environmental assurance through compliance with RoHS regulations
Durable construction ensures longevity in challenging conditions
Compact design that maximises installation space and efficiency
Meets stringent safety standards for electrical equipment
Versatile voltage rating suitable for a variety of applications
Ideal for use in both commercial and advanced industrial environments
Provides peace of mind with a high number of operational cycles
