Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 10 A, Type C, 440 V ac AC, 60 V DC, 7.5 kA Breaking Capacity
- RS Stock No.:
- 254-675
- Mfr. Part No.:
- 241145 FAZT-C10/3N
- Brand:
- Eaton
Subtotal (1 unit)*
£310.08
(exc. VAT)
£372.10
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £310.08 |
*price indicative
- RS Stock No.:
- 254-675
- Mfr. Part No.:
- 241145 FAZT-C10/3N
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 3 | |
| Current Rating | 10 A | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 440 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 7.5kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Height | 75.5mm | |
| Depth | 80mm | |
| Width | 72 mm | |
| Standards/Approvals | EAN, EN45545, EN 6000:018, EN 608981:019, IEC 617, IECEN 60947, IECEN 6149, RoHS | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 3 | ||
Current Rating 10 A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 440 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 7.5kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Height 75.5mm | ||
Depth 80mm | ||
Width 72 mm | ||
Standards/Approvals EAN, EN45545, EN 6000:018, EN 608981:019, IEC 617, IECEN 60947, IECEN 6149, RoHS | ||
- COO (Country of Origin):
- RO
The Eaton Moeller series xEffect FAZ T miniature circuit breaker is engineered for advanced protection in industrial and commercial applications. Designed with a robust three pole plus neutral configuration, it features a tripping characteristic that efficiently handles varying electrical loads. The regulatory compliance, including RoHS and IEC/EN certifications, showcases its reliability and adherence to high safety standards. With a rated current of 10 A and a maximum operational voltage of 440 VAC, this device ensures exceptional performance under diverse operating conditions. Its compact design allows for easy installation on standard top hat rails, while the IP20 rating guarantees adequate protection against ingress. This circuit breaker not only aligns with contemporary standards but is tailored for those who seek both functionality and quality in their electrical systems.
Robust mechanical lifespan guarantees durability and longevity
Compact dimensions optimise space utilisation in electrical panels
Quick attachment mechanism simplifies the installation process
Conforms to multiple standards for a broad range of applications
Designed to ensure safe operation in both industrial and advanced commercial environments
Effective heat dissipation promotes device efficiency and reduces thermal risk
Ambient temperature considerations enhance reliability in varied settings
Finger and hand touch safe terminals provide an additional layer of safety
Twin purpose terminals allow for flexible conductor connections
Achieves significant current limiting enhancing protection against overloads
