Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 15 A, Type B, 230 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 254-659
- Mfr. Part No.:
- 241005 FAZT-B15/1N
- Brand:
- Eaton
Subtotal (1 unit)*
£69.87
(exc. VAT)
£83.84
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £69.87 |
*price indicative
- RS Stock No.:
- 254-659
- Mfr. Part No.:
- 241005 FAZT-B15/1N
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 1 | |
| Current Rating | 15 A | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 230 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Depth | 80mm | |
| Width | 36 mm | |
| Height | 75.5mm | |
| Standards/Approvals | IEC/EN 60947-2, IEC 61373, EN45545-2 | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 1 | ||
Current Rating 15 A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 230 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Depth 80mm | ||
Width 36 mm | ||
Height 75.5mm | ||
Standards/Approvals IEC/EN 60947-2, IEC 61373, EN45545-2 | ||
- COO (Country of Origin):
- RO
The Eaton Moeller series xEffect FAZ T miniature circuit breaker is engineered to deliver reliable protection for your electrical systems. With its compact design, this model combines essential functionality and sophisticated safety features, making it an ideal choice for industrial and advanced commercial applications. Designed for simplicity, the device caters to a range of setups while ensuring compliance with stringent industry standards. Its adaptability allows for quick installation on top hat rails, and with a rated current of 15 A, it provides efficient circuit protection, significantly reducing the risk of electrical faults. This product is not just a component; it embodies Eaton's commitment to quality, performance, and longevity, ensuring that electrical installations remain safe and compliant.
Compact size enhances space efficiency in installations
Turns potential electrical risks into manageable safety
Maintains consistent operation across various temperatures
Integrates smoothly with existing electrical distribution systems
Supports advanced applications with robust short circuit protection
Designed for easy maintenance and accessibility
Tested to meet exacting industry standards for reliability
Offers versatile mounting options tailored to user preferences
