Eaton xEffect FAZ MCB, 1+N, 16A Curve B, 230V AC, 60V DC, 7.5 kA Breaking Capacity
- RS Stock No.:
- 254-186
- Mfr. Part No.:
- 241009 FAZT-B16/1N
- Brand:
- Eaton
Subtotal (1 unit)*
£57.40
(exc. VAT)
£68.88
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £57.40 |
*price indicative
- RS Stock No.:
- 254-186
- Mfr. Part No.:
- 241009 FAZT-B16/1N
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Eaton | |
Number of Poles | 1+N | |
Current Rating | 16A | |
Tripping Characteristics | Type B | |
Rated AC Voltage | 230V | |
Rated DC Voltage | 60V | |
Breaking Capacity at Maximum Voltage Rating | 7.5 kA | |
Range | xEffect | |
Series | FAZ | |
Select all | ||
---|---|---|
Brand Eaton | ||
Number of Poles 1+N | ||
Current Rating 16A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 230V | ||
Rated DC Voltage 60V | ||
Breaking Capacity at Maximum Voltage Rating 7.5 kA | ||
Range xEffect | ||
Series FAZ | ||
- COO (Country of Origin):
- RO
The Eaton Moeller series xEffect FAZ T MCB is the ideal solution for those seeking reliable and efficient miniature circuit breakers designed for industrial and advanced commercial applications. Offering comprehensive protection and adaptability, this product excels in various environments with its dynamic performance characteristics. Its innovative engineering allows for precise current management, ensuring optimal operation even in challenging conditions. Incorporating cutting edge technology, the FAZ T series guarantees both compliance with stringent standards and user friendly installation. With a robust design capable of withstanding high demands, it ensures longevity and peace of mind for users, establishing itself as a crucial component in your electrical protection system.
Compact 2 modular spacing design for versatile installations
User friendly quicker attachment mechanism for easy mounting
Exceptional ambient temperature range for enhanced operating conditions
Superior short circuit breaking capacities to ensure reliable protection
Finger and hand touch safe terminals for increased safety
Conforms to IEC and EN international standards for assurance
Sustainable with RoHS compliance ensuring environmental responsibility
Innovative characteristic curve B to manage different load types effectively
User friendly quicker attachment mechanism for easy mounting
Exceptional ambient temperature range for enhanced operating conditions
Superior short circuit breaking capacities to ensure reliable protection
Finger and hand touch safe terminals for increased safety
Conforms to IEC and EN international standards for assurance
Sustainable with RoHS compliance ensuring environmental responsibility
Innovative characteristic curve B to manage different load types effectively
