Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 40 A, Type B, 415 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 247-658
- Mfr. Part No.:
- 132730 FAZ-B40/3-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£196.99
(exc. VAT)
£236.39
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £196.99 |
*price indicative
- RS Stock No.:
- 247-658
- Mfr. Part No.:
- 132730 FAZ-B40/3-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 40 A | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Depth | 45mm | |
| Height | 105mm | |
| Standards/Approvals | CSA C. . 5, EN45545, IEC 60947, IEC 617, UL 489 | |
| Width | 70.5 mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 40 A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Depth 45mm | ||
Height 105mm | ||
Standards/Approvals CSA C. . 5, EN45545, IEC 60947, IEC 617, UL 489 | ||
Width 70.5 mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker is a high-performance miniature circuit breaker designed specifically for demanding electrical applications in North America. Engineered for efficiency and safety, this robust device provides reliable protection for feeder and branch circuits while ensuring compliance with stringent UL and CSA standards. Its three-pole configuration combined with a tripping characteristic of B allows for enhanced overcurrent protection, making it an ideal choice for both residential and commercial installations.
Features a robust IP40 degree of protection for enhanced durability
Includes finger and hand touch safe terminals to ensure user safety
Designed to handle a maximum rated operational voltage of 415 V
Offers a lifespan of up to 2,000 operations for reliable long-term performance
