Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 1 A, Type D, 240 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 247-131
- Mfr. Part No.:
- 102138 FAZ-D1/1-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£26.99
(exc. VAT)
£32.39
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 3 unit(s) ready to ship from another location
- Plus 18 unit(s) shipping from 17 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £26.99 |
*price indicative
- RS Stock No.:
- 247-131
- Mfr. Part No.:
- 102138 FAZ-D1/1-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 1 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 1 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 240 V ac | |
| Rated DC Voltage | 60 V | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Width | 17.7 mm | |
| Height | 75.5mm | |
| Depth | 70.5mm | |
| Standards/Approvals | RoHS, CSAC. . 509 etc | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 1 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 1 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 240 V ac | ||
Rated DC Voltage 60 V | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Width 17.7 mm | ||
Height 75.5mm | ||
Depth 70.5mm | ||
Standards/Approvals RoHS, CSAC. . 509 etc | ||
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series is designed for industrial and advanced commercial applications. With its robust construction, the device ensures reliable protection against overcurrents and short circuits, safeguarding your electrical installation effectively. Its compact dimensions provide flexibility in installation, allowing for easy integration into existing systems. The device not only meets stringent electrical standards but also ensures safety with features such as finger and hand touch protection, enhancing usability in various environments.
Rated short circuit breaking capacity guarantees reliable fault isolation
Designed for top hat rail mounting for effortless installation
Wide operational temperature range supports varied operating conditions
Optimised for use in North American electrical systems meeting local compliance
Superior insulation voltage ensures maximum safety during operation
Meets multiple international standards for quality and reliability
