Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 3 A, Type D, 415 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 241-215
- Mfr. Part No.:
- 102261 FAZ-D3/3-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£233.72
(exc. VAT)
£280.46
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £233.72 |
*price indicative
- RS Stock No.:
- 241-215
- Mfr. Part No.:
- 102261 FAZ-D3/3-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 3 | |
| Current Rating | 3 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 15kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP40, IP20 | |
| Width | 53.1 mm | |
| Height | 75.5mm | |
| Standards/Approvals | UL (File No. E235139), UL (Category Control Number DIVQ), UL 489, North America (UL,CSA ), IEC/EN 60947-2, IEC 60947-2, CSA (File No. 204453), CSA (Class No. 1432-01), CSA-C22.2 No. 5-09, CSA C22.2 No. 5, CE marking | |
| Depth | 70.5mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 3 | ||
Current Rating 3 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 15kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP40, IP20 | ||
Width 53.1 mm | ||
Height 75.5mm | ||
Standards/Approvals UL (File No. E235139), UL (Category Control Number DIVQ), UL 489, North America (UL,CSA ), IEC/EN 60947-2, IEC 60947-2, CSA (File No. 204453), CSA (Class No. 1432-01), CSA-C22.2 No. 5-09, CSA C22.2 No. 5, CE marking | ||
Depth 70.5mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series designed specifically for the demands of North American environments. With a robust tripping characteristic rated at D, it delivers reliable protection for feeder and branch circuits operating on both AC and DC voltage systems. This device is UL listed and CSA certified, ensuring superior performance and compliance with international safety standards. Its compact dimensions and robust features guarantee a solid performance, catering to the diverse needs of modern electrical systems while maintaining a commitment to efficiency and safety.
IP20 protection rating
Finger and hand touch safe terminal design
Designed for 20000 electrical operations
