Eaton xEffect FAZ MCB, 3P, 1A Curve D, 415V AC, 60V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 241-213
- Mfr. Part No.:
- 102258 FAZ-D1/3-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£200.68
(exc. VAT)
£240.82
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £200.68 |
*price indicative
- RS Stock No.:
- 241-213
- Mfr. Part No.:
- 102258 FAZ-D1/3-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Eaton | |
Number of Poles | 3 | |
Current Rating | 1A | |
Tripping Characteristics | Type D | |
Rated AC Voltage | 415V | |
Rated DC Voltage | 60V | |
Breaking Capacity at Maximum Voltage Rating | 15 kA | |
Range | xEffect | |
Series | FAZ | |
Select all | ||
---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Current Rating 1A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415V | ||
Rated DC Voltage 60V | ||
Breaking Capacity at Maximum Voltage Rating 15 kA | ||
Range xEffect | ||
Series FAZ | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series is designed to meet the rigorous standards of North American voltage applications. Combining safety and reliability, it is a vital component for both feeder and branch circuits. Built for superior performance, this device offers a three pole configuration with a tripping characteristic of D, making it ideal for accommodating a wide range of operational demands. The switchgear is UL listed, ensuring compliance with strict safety and performance requirements.
Three pole design optimised for North American applications
UL listed certification ensures adherence to safety regulations
Compact dimensions for ease of installation in tight spaces
Robust construction designed to withstand up to 20000 electrical operations
IP20 protection degree providing a safe and secure interface in various environments
UL listed certification ensures adherence to safety regulations
Compact dimensions for ease of installation in tight spaces
Robust construction designed to withstand up to 20000 electrical operations
IP20 protection degree providing a safe and secure interface in various environments
