Schneider Electric Multi9 M9F1 MCB, 2P, 16A Curve D, 440V AC, 125V DC, 6 kA Breaking Capacity

View all MCBs

Subtotal (1 unit)*

£105.04

(exc. VAT)

£126.05

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 999,999,999 unit(s) shipping from 14 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£105.04

*price indicative

RS Stock No.:
212-129
Mfr. Part No.:
M9F12216
Brand:
Schneider Electric
Find similar products by selecting one or more attributes.
Select all

Brand

Schneider Electric

Number of Poles

2

Current Rating

16A

Tripping Characteristics

Type D

Rated AC Voltage

440V

Rated DC Voltage

125V

Breaking Capacity at Maximum Voltage Rating

6 kA

Range

Multi9

Series

M9F1

COO (Country of Origin):
BG
The Schneider Electric Miniature Circuit Breaker is designed for distribution applications and supports both AC and DC networks. It features thermal-magnetic trip unit technology for reliable overcurrent protection. It has a rated operational voltage of 240 V AC, 415 V AC and 440 V AC, operating at 50/60 Hz. It also has a rated insulation voltage of 500 V AC at 50/60 Hz. The breaker includes a contact position indicator and a toggle control type for easy operation. Local ON/OFF indication provides clear status signalling, and it operates within an ambient temperature range of -30 to 70°C.

Clip on mounting
Din rail mounting support
IP40 rated for modular enclosure conforming to IEC 60529
