ABB System Pro M Compact S200M Miniature Circuit Breaker, 3-Pole, 8A, Type D, 400V ac AC, 125 V dc DC, 15 kA Breaking
- RS Stock No.:
- 203-887
- Mfr. Part No.:
- 2CDS273001R0081
- Brand:
- ABB
Subtotal (1 unit)*
£96.15
(exc. VAT)
£115.38
(inc. VAT)
FREE delivery for orders over £50.00
Stocked by manufacturer
- Ready to ship from 08 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £96.15 |
*price indicative
- RS Stock No.:
- 203-887
- Mfr. Part No.:
- 2CDS273001R0081
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 3 | |
| Current Rating | 8A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 400V ac | |
| Rated DC Voltage | 125V dc | |
| Breaking Capacity | 15kA | |
| Mount Type | DIN Rail | |
| Range | System Pro M Compact | |
| Series | S200M | |
| Terminal Type | Screw | |
| IP Rating | IP40, IP20 | |
| Standards/Approvals | UNSPSC, UL 1077, UKCA, RoHS, REACH, IEC/EN 60947-2, IEC/EN 60898-1, IDEA, ETIM, CSA 22.2 No. 235, CE | |
| Depth | 69mm | |
| Height | 88mm | |
| Width | 52.5mm | |
| Tripping Mechanism | Anaerobic Adhesive | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 3 | ||
Current Rating 8A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 400V ac | ||
Rated DC Voltage 125V dc | ||
Breaking Capacity 15kA | ||
Mount Type DIN Rail | ||
Range System Pro M Compact | ||
Series S200M | ||
Terminal Type Screw | ||
IP Rating IP40, IP20 | ||
Standards/Approvals UNSPSC, UL 1077, UKCA, RoHS, REACH, IEC/EN 60947-2, IEC/EN 60898-1, IDEA, ETIM, CSA 22.2 No. 235, CE | ||
Depth 69mm | ||
Height 88mm | ||
Width 52.5mm | ||
Tripping Mechanism Anaerobic Adhesive | ||
- COO (Country of Origin):
- DE
The ABB Miniature Circuit Breaker offers precise and reliable protection against overloads and short circuits. Designed for residential, commercial, and industrial use, it adheres to IEC/EN standards, ensuring safety and performance. Its compact size optimizes space on mounting rails while accommodating various configurations to meet specific needs. The advanced thermal tripping technology and robust breaking capacity ensure dependable operation.
Three-pole design provides enhanced protection for multiple circuits
Compact design fits easily onto DIN rails, saving space
Supports addition of auxiliary contacts for expanded functionality
Delayed thermal tripping mechanism improves overload protection
